GE CARESCAPE B650 Features The efficient and ergonomic CARESCAPE* Monitor B650 offers flexibility at every point of care. Configurability, a user-friendly interface, outstanding parameters and seamless integration all ensure that you can focus on the patient instead of the technology. The CARESCAPE Monitor B650 has the advanced tools to meet the needs of CCU, PACU, NICU, and lower-acuity ICU and OR patients. Seamlessly integrate with GE Healthcare Engstrom and Anesthesia Carestation devices with remote on/off function, so monitoring can begin at the anesthesia station. Get full data continuity with CARESCAPE Patient Data Module for seamless patient data capture in HIS/ EMR. Clinically outstanding parameters help enable better quality of care: dual Sp02, continuous metabolics and gas exchange, Ek-Pro arrhythmia analysis, and Adequacy of Anesthesia parameters, such as Entropy and NMT. Diagnostic cardiac excellence at the bedside with 12SL* ECG analysis and two-way integration to the MUSE* cardiology information system, allowing fast, validated access to a patient’s 12SL history and serial comparison of cardiac status. Combination monitoring with Apex Pro* telemetry allows early mobility of patients that may help reduce the length of stay. GE CARESCAPE B650 Specifications Dimensions Size: (H x W x D) 29 x 30 x 16 cm (11.4 x 11.9 x 6.2 in) Weight: 5.0 kg (11.0 lb) with all options and battery, without modules Display Size: 12 in (diagonal) Type: Active matrix color TFT LCD Resolution: 1024 x 768 pixels (XGA) Number of traces: 6 (max) Sweep speed: 0.625, 6.25, 12.5, 25, 50 mm/sec Configuration: Automatic configuration according to parameter avavilability. Manual configuration with up to 8 user configurable profiles for carespecific configurations, and up to 6 user-configurable display pages for each profile. Controls Touch screen: Standard Power on: Front of unit Remote control (USB): Optional 11 keys to facilitate non touch use: Alarm Setup, Monitor Setup, Procedures, Trends, Data & Pages, Print Waveforms, Freeze/ Snapshot, NIBP Auto, NIBP Start/ Stop, Parameters and Zero ALL pressures Networking Compatibility: CARESCAPE Network, S/5 Network, MUSE ECG database, Unity Network ID Features: Centralized viewing and remote alarm management with bedtobed viewing and AVOA functionality Network type: LAN, WLAN (optional) WLAN communication protocol (optional): IEEE 802.11a/b/g Operating frequency: 2.4 GHz and 5 GHz Data rate: 1 - 54 Mbps I/O Connectors Ethernet: 3 RJ45 for IX, MC, Unity Network ID Serial Port: Available via USB converter Slave/independent screen: 1 DVI-D out USB Port: 2 USB 2.0 ePort: 1 E-port Analog output Proprietary analog output connector on CARESCAPE Patient Data Module. Analog output connector (MiniDIN 7) on the monitor frame is for Patient Side Module (PSM) use only Remote-On: Remote power on control input for anesthesia machine integration Alarms Categories: Patient status and system status Priority: High, Medium, Low, Escalating, and Informational In accordance with IEC 60601-1-8 Notification: Audible and visual Audio pause, active alarms: 2 min Audio pause, all alarms: 2 or 5 min Trend 1 min resolution: 72h 10 s resolution: 30min 2 s resolution: 24h Snapshot 15 s Waveform: 400 snapshots ST: 10 snapshots Events: 999 events Power Supply Universal input voltage range: 100 to 240 Vac +/-10%, 50/60 Hz Power consumption: < 200 VA Protection class; Class I Grounding: Hospital grade Cooling: Natural convection – no fans Battery (Optional) Type: Exchangeable Lithium-Ion Number of batteries: 1 or 2 Voltage: 10.8 V (nominal) Capacity: 3.8 Ah per battery, 7.6 Ah with 2 batteries (min) Charge time: 2 to 3 hours per battery, depending on configuration Run time: 3.5 hours, depending on configuration Battery life: 300 cycles to 60% capacity Operating Conditions Temperature: 10 to 35°C (50 to 95°F) Relative humidity: 10 to 90% non-condensing Storage Conditions Temperature: -20 to 60°C (-4 to 140°F) Relative humidity: 10 to 90% non-condensing
