Datascope Spectrum OR Features Built-in, vivid 12.1-inch display with auto-adjustablelarge numerics and waveforms for optimal visibility. Includes the standard functions you need for perianesthesia monitoring including 3 or 5-lead ECG, non-invasive blood pressure, Masimo SET. Motion tolerant SpO2, temperature, and drug calculations. Offers various options to best meet your department's needs including microstream, CO2, BISx Module, Nellcor, OxiMax, SpO2, cardiac output, continuous cardiac output/SvO2*, invasive blood pressures, ST and arrhythmia analysis and more. Datascope Spectrum OR Specifications DISPLAY Size: 12.1-inch (30.7cm) Color Active Matrix TFT LCD Resolution: 800 x 600 pixels Waveforms: 3 to 8 ECG (3-LEAD AND 5-LEAD) Leads: I, II, III, aVR, aVL, aVF, V Cable Detection: Autodetecting Datascope 3 or 5 wire Display Sensitivity: 0.25, 0.5, 1.0, 2.0, 3.0, 4.0, cm/mV ± 10% Frequency Response To Screen Extended Mode: 0.05 – 100 Hz, -3db Monitor Mode: 0.5 – 40 Hz, -3db ST Mode: 0.05 – 40 Hz, -3db ECG Sync Pulse for Cardioversion: Delay: ≤35 ms max between QRS Peak and rising edge of Sync Pulse Amplitude: 2Vp minimum into a 5k ohm load Width: 2-7 ms Analog Output: (ECG) Delay: 25 ms max Sensitivity: 1 V/mV of input, ± 10% Defibrillator Overload Protection: Withstand 360 Joule discharge as per IEC 60601-2-27, 51.101.1 Recovery Time: Time for recovery to within 1mV in < 8 seconds automatically. 3 seconds from 1Vpp at 60 Hz HEART RATE METER Range: 30 – 300 BPM Adult/Pediatric, 30 – 350 BPM Neonate Accuracy: ± 3 BPM or ± 3% at 30 – 250 BPM whichever is greater, ± 5% at 251 – 350 BPM Pacer Rejection: Rejects all pulses of amplitude ± 2.0 mV to ± 700 mV and duration 0.1 to 2 ms with no tail. AAMI EC-13-1992 4.1.4 (3-Lead and 5-Lead) Rejects all pulses of amplitude ± 2.0 mV to 700 mV and duration 0.1 to 2ms with 100 ms time constant tail of less than 2.0 mV, or 4 ms time constant tail of < 2.0 mVper AAMI EC-13-1992 3.1.4.2 Tall T-Wave Rejection: Rejects all T-Waves of amplitude less than 120% of 1 mV, 100 ms QRS, T wave duration of 180 ms and Q-T interval of 350 ms per AAMI EC-13-1992 4.1.2.1 (c) ST ANALYSIS 3-lead or 5-lead Range: -9.9 mm to +9.9 mm Resolution: 0.1 mm Default ST Measuring Point: 80 ms after j point for HR <120 BPM, 60 ms after j point for HR >120 BPM ARRHYTHMIA ANALYSIS 3-lead or 5-lead cables: Adult / Pediatric Only: Asystole, Irregular Heart Rate, Couplets, Bigeminy, Trigeminy, Ventricular Tachycardia, Ventricular Fibrillation, PVC’s per minute, Runs, Ventricular Rhythm RESPIRATION (ECG) Range: 4 to 199 BPM Accuracy: ± 2% or 2 breaths per minute whichever is greater from 4 to 150 BPM, ± 4% from 151 to 199 BPM Lead: I or II NON-INVASIVE BLOOD PRESSURE Technique: Oscillometric Systolic Range: Adult: 55 - 235 mmHg, Pediatric: 55 - 160 mmHg, Neonate: 45 - 120 mmHg Diastolic Range: Adult: 30 - 200 mmHg, Pediatric: 30 - 150 mmHg, Neonate: 20 - 100 mmHg Systolic Accuracy: Mean Error less than ± 5 mmHg, standard deviation less than ± 8 mmHg Diastolic Accuracy: Mean Error less than ± 5 mmHg, standard deviation less than ± 8 mmHg Pulse Rate Range: Adult/Pediatric: 35 to 245 BPM Neonate: 70 to 245 BPM Pulse Rate Accuracy: ±3 BPM or 3% whichever is greater Connector Type: Rectus Cuff Inflation: Volume of 500 cc to 300 mmHg in ≤35 sec TEMPERATURE Scale: Selectable C˚ or F˚ Range: 15˚ to 45˚C / 59˚ to 113˚F (T1 and T2) 0˚C to 5.5˚C / 0˚F to 9.9˚F (Delta T) Accuracy: ± 0.1˚C (15˚C to 45˚C) exclusive of probe errors. ± 0.2˚F (59˚F to 113˚F) exclusive of probe errors. PULSE OXIMETRY Masimo SET® SpO2 Accuracy Saturation with no motion conditions Adult/Pediatric: 70% to 100% ± 2 digits SpO2, 0 to 69% unspecified Neonate: 70% to 100% ± 3 digits SpO2, 0 to 69% unspecified Ear Sensor (Adult/Pediatric): 70% to 100% ± 4 digits SpO2, 0 to 69% unspecified Masimo SET® SpO2 Accuracy Saturation during motion conditions Adult/Pediatric/Neonate: 70% to 100% ± 3 digits SpO2 Response Time: 18 seconds to 95% of final step of % SpO2 value from 60-95% at 75 BPM. Averaging set at 8 seconds. Pulse Rate Range Masimo with no motion conditions Adult/Pediatric/Neonate: 30-235 ±3 BPM, Ear Sensor (Adult/Pediatric) 30-235 ± 3 BPM Pulse Rate Range Masimo during motion conditions Adult/Pediatric/Neonate: 30-235 ±5 BPM Low Perfusion Performance Masimo: > 0.02% Pulse Amplitude and % Transmission > 5% / Saturation (%SpO2) ± 2 digits; Pulse ± 3 digits Nellcor® OxiMax® SpO2 Saturation Accuracy Adult/Pediatric/Neonate: 70% to 100% ± 3 digits Pulse Rate Range Nellcor: 20-249 ±3 BPM IBP Range: Sys/Dia/Mean -30 to +300 mmHg Accuracy: ± 2 mmHg or 2% whichever is greater Scale: -10 to 10, 0-20, 0-40, 0-160, 0-225, 0-320, 60-140 mmHg Zero Range: ± 120 mmHg Excitation: 5V DC ± 2% Frequency Response: DC to 16 Hz ± 1Hz, -3db RECORDER Speed: 3.125, 6.25, 12.5, 25 mm, and 50 mm/sec Note: 3.125 speed is for CO2/Resp only. CO2 (MICROSTREAM®) Range: 0 – 99 mmHg Accuracy: 0 – 38 mmHg ± 4 mmHg 39 – 99 mmHg ± 12% (0 – 20 min) 0 – 38 mmHg ± 2 mmHg 39 – 99 mmHg ± 5% + .08% for every 1mmHg above 40 mmHg (> 20 min) Respiration Rate: 0-150 breaths per minute Respiration Accuracy: ± 1 breath per minute from 0 – 40 BPM ± 2 BPM from 41– 70 BPM ± 3% from 71 – 100 BPM ± 5% from 101 – 150 BPM CO2 Waveform Recognition: 5 mmHg ± 2 mmHg bandwidth Start-up Time: 30 seconds typical Sampling Rate: 50 ml/min ± 7.5 ml/min Auto Zero: <15 seconds at 5, 10, 15 and 60 minutes, then every 60 minutes thereafter. ELECTRICAL RATINGS AC Voltage: 100 – 240 VAC ± 10%, 50/60 Hz ± 3 Hz Battery Type: Sealed Lead Acid Number of Batteries: 2 Battery Voltage: 12 V Battery Capacity: 2.3 Ah Battery Run Time: 1 hour, 20 min from two fully charged, new batteries at 25°C with ECG, SpO2 and NIBP running at 15 minute intervals Recharge Time: 16 hrs max PHYSICAL DIMENSIONS Monitor Size: 26.7cm H x 30.2cm W x 18.8cm D 10.5" H x 11.9" W x 7.4" D without module 27.2cm H x 30.2cm W x 18.8cm D 10.7" H x 11.9" W x 7.5" D with module Weight: 5.43 kg (11.95 lbs) without optional accessories 7.04 kg (15.52 lbs) with 2 batteries, without optional accessories 0.8 kg (1.75 lbs) module, without optional accessories CARDIAC OUTPUT Range: 0.2 to 20.0 liters/min C.O. Repeatability: ± 2% or 0.02 l/min from the mean value Blood Temp Range: 17.5°C to 43°C (63.5°F to 109.4°F) Blood Temp Accuracy: ± 0.2°C (± 0.4°F) exclusive of probe errors Injectate Temp Range: -1.0°C to 30.0°C (30.2°F to 86°F ) Injectate Temp Accuracy: ± 0.2°C (± 0.4°F) exclusive of probe errors BIS (BISPECTRAL INDEX) Bispectral Index (BIS) Range: 0 - 99 Signal Quality Index (SQI) Range: 0 - 100% EMG Range: 30 - 80dB Suppression Ratio (SR): 0 - 100% Burst Count: 0 - 30 Input Impedance: >50 Mohm Noise (RTI): <0.3uV RMS 0.25 - 50 Hz Input Range: +/- 1mV EEG Bandwidth: 0.25 - 100Hz (-3dB) FILTERS (ON) High Pass: 2.0 Hz (-3dB) Low Pass: 70 Hz (-3dB) Notch: 50 Hz and 60 Hz FILTERS (OFF) High Pass: 0.25 Hz (-3dB) Low Pass: None Notch: None MAC (MINIMUM ALVEOLAR CONCENTRATION) The Spectrum OR shall compute the uncorrected MAC value for all agents supported by the Gas Module SE using the following formula: Where AA is the anesthetic agent in use, ET AA is the end-tidal agent concentration, x(AA) is a clinically derived coefficient based on anesthetic agent (known as 1MAC values), ET N2O is the end-tidal N2O concentration and x(N2O) is a clinically-derived coefficient for N2O (also known as the 1MAC value). X(Isoflurane) = 1.15% X(Halothane) = 0.77% X(Sevoflurane) = 2.1% X(Desflurane) = 7.3% X(Enflurane) = 1.7% X(N2O) = 105% The uncorrected MAC value is not corrected for ambient pressure (altitude & barometric effects), patient age, patient core temperature or any other individual factors influencing the effect of volatile anesthetic agents. Reference Source: EN ISO 21647:2004 Medical electrical equipment- Particular requirements for the basic safety and essential performance of respiratory gas monitors. Vigilance® Interface: Supports the Vigilance IFM out communication protocol in accordance with Edwards Lifesciences specification ELS 1291 RevF
