Physio Control Battery Support System 2 (Bss2)
Details
Physio Control Battery Support System 2 Features Features The Battery Support System II from Physio Control significantly increases battery performance for all LifePak defibrillator units that use the FastPak battery or SLA Batteries by Medtronic Physio-Control. For LifePak 12, LifePak 11, and LifePak 10 Transport Defibrillators. Innovative platform design provides ease of use and the flexibility to add new features and enhancements to support future battery technologies. The push-button fuel gauge in FASTPAK 2 and LIFEPAK NiCd batteries provides a quick and easy check of the battery capacity. The high-capacity LIFEPAK NiCd battery makes it ideal for use with multiparameter monitoring. In addition, LIFEPAK NiCd engages the battery capacity symbols on the LIFEPAK 12 device screen to provide a clear indication of its charge level. The LIFEPAK SLA battery is well-suited for the low-use environment. Physio Control Battery Support System 2 Specifications General Specifications Dimensions: 31.5 x 37.6 x 9.7 cm (12.4 x 14.8 x 3.8 in) Weight: < 8.2 kg (18 lbs) (excluding batteries) Number of Battery Wells: 3 Charging, conditioning and shelf life test capability in all battery wells. Power Requirements: Commercial: 100/120/220/240 V AC ± 10%, 50/60 ± 3 Hz Military: 100/120/220/240 V AC ± 10%, 50/60 ± 3 Hz, 400Hz +/- 7Hz Fuses: Two fuses in the power input module (5 x 20 mm F 1A 250 V, Low or High break capacity) per IEC 127-2, sheet 1 or 2, such as Bussman GDA or GDB, Littelfuse 216, or Schurter SP or SFS Environmental Specifications Not protected against ingression of fluids. Indoor use only Altitude, Operating: To 4,572 m (15,000 ft) Altitude, Non-operating: To 5,500 m (18,045 ft) Humidity: 5 to 95% Temperature, Operating: 5° to 45°C (41° to 95°F) (commercial) 0° to 50°C (32° to 122°F) (U.S. Military) Temperature, Storage: -40° to 70°C (-40° to 158°F) (commercial) -46° to 71°C (-51° to 160°F) (U.S. Military) Vibration: IEC 68-2-6 (commercial) MIL-STD-810E, Method 514.4 Category 4, 6, 8 (U.S. Military)
Additional Information
General Information About Defibrillators Why Defibrillation? Sudden Cardiac Arrest (SCR)-Rapid irregular rhythm causing heart to quiver Cause: Ventricular Fibrillation (VF) Can lead to death if emergency shock not delivered Defibrillation – to counteract fibrillation Defibrillator Device used to administer an electric current (shock) to the heart Types of Defibrillators Manual external Manual Internal Automated External (AED) Semi-Automated External Implantable Cardioverter-Defibrillator (ICD) Manual External Defibrillator Widely used in Hospitals and clinics Inbuilt EKG reader Clinician Diagnoses the condition and accordingly administers the shock through paddles or pads Manual Internal Defibrillator Exclusively used in Operation Theatres Charge delivered through internal paddles in direct contact with the heart Automated External Defibrillator (AED) Used by lay persons requiring little training Built in heart rhythm analyzer Advices whether shock is required Semi-Automated External Defibrillators Used by paramedics and emergency medical technicians Automated capabilities of AED With ECG display and manual over ride option Implantable Cardioverter Defibrillator Implants similar to pacemakers Constantly monitor heart rhythm Automatically administers shock for arrhythmias Types of waveform - Shape of defibrillation current Monophasic damped sine waveform – delivers energy in one direction Relies on adjustment of joule settings Biphasic damped sine waveform – bi-directional current flow Measures impedance of patient and delivers precise dose of electricity Uses significantly low energy levels Decreases risk of burn in Myocardial damage
