Verathon BladderScan Prime Features The BladderScan Prime portable 3D ultrasound instrument redefines accuracy and makes ease-of-use easier than ever. It’s a workhorse device that reduces downtime and raises the quality of care, delivering long-lasting value. It supports evidence-based catheter management, along with consistent, comfortable assessment of patients. To promote long and uninterrupted service, reliability is built into every BladderScan Prime system. In the event of a drop, Prime has a built‑in mechanical diagnostic to confirm it’s still working properly. NeuralHarmonics enables more accurate measurements than conventional two-dimensional ultrasound. In bladder volume measurements, a unique second harmonic differentiates the bladder, urine, and hypo-echogenic regions, such as the uterus. This results in a better analysis and a more accurate measurement from the device. With one button press, VMODE® technology acquires multiple scan planes to produce a 3-dimensional quantification of the bladder. Based on this quantification, the instrument automatically calculates and displays urinary bladder volume. Touch screen controls Live B-mode pre-scan aiming Ergonomic new probe design Intuitive user interface Premium rolling cart (optional) with integrated storage and cable management Onboard help/tutorial for training and ease-of-use Scan from either side of the patient Verathon BladderScan Prime Specifications Dimensions Console General Height 125 mm (4.92 in) Width 227 mm (8.94 in) Depth 259 mm (10.20 in) Weight 1770 g (3.90 lbs) Display 1280 x 800 pixels Electrical Input Verathon Supplied Battery, 11.7 V DC Output USB Ports, 5 V DC at 100 mA maximum from each port Insulation Type BF Probe General Height 196 mm (7.70 in) Width 62 mm (2.43 in) Depth 62 mm (2.43 in) Weight 580 g (1.28 lbs) Display 144 x 168 pixels Cable 1.8 m (6.0 ft) Printer General Height 70 mm (2.76 in) Width 164 mm (6.45 in) Depth 90 mm (3.54 in) Weight (without paper) 352 g (0.78 lbs) Resolution 8 dots/mm (203 dots/in) Dot size 0.125 mm by 0.12 mm (0.005 in by 0.005 in) Printing width 48 mm (1.89 in), or 384 dots/line Battery General Battery type Lithium Ion (Li‑Ion) Height 23 mm (0.89 in) Width 151 mm (5.94 in) Depth 59 mm (2.32 in) Weight 326 g (0.72 lbs) Electrical Battery life A fully charged battery will typically provide over 24 hours of normal operating use between charges Charging time 2.5 hours (typical) Rated capacity 4.6 Ah, 51 Wh Nominal voltage 11.1 V Max charging voltage 12.6 V General Classification Internally powered, Type BF Expected Product Life Console: 7 years Probe: 7 years Printer: 7 years Battery Charger: 7 years Ingress Protection (IP) Against Water Console IPX0 Probe IPX4 Printer IPX0 Battery charger IPX0 Battery IPX0 Operating Conditions Use: Indoor Temperature: +10 to +40°C (50 to 104°F) Relative Humidity: 20 to 75% Ambient Air Pressure: +700 hPa to 1060 hPa Storage Conditions Use: Indoor Temperature: ‑10 to +60°C (14 to 140°F) Relative Humidity: 20 to 80% Ambient Air Pressure: +600 hPa to 1060 hPa Accuracy Bladder Volume Range: 0 to 999 mL Volume Accuracy: ± (15% ± 15 mL)
