Vyaire Nonin 7500 Series Features The Vyaire Nonin 7500 Series pulse oximeter has a unique low-profile design that enables it to fit easily on a tabletop or into its own carrying case. The stylish, compact 7500’s simple functionality, minimum 16-hour battery life, 4-hour quick recharge, and a minimum of 70 hours of memory makes it well-suited for a variety of clinical and homecare applications. Convenient – Lightweight and compact Easy-To-Use – Bright LED displays and large display screen offer clear readability Durable – Rugged design Powerful – Over 70 hours of memory available for extended monitoring Versatile – Monitors neonate to adult patients in acute care to homecare environments Flexible – Use as a stand-alone device or interface with other equipment Vyaire Nonin 7500 Series Specifications Dimensions Height: 3.6 In (9.2 cm) Width: 8.6 In (21.9 cm) Depth: 5.6 In (14.2 cm) Weight: 2 lbs (0.9 kg) Oxygen Saturation Display Range 0–100% SpO2 Pulse Rate Range 18–321 BPM Saturation Accuracy 70–100% Adults / Pediatrics No Motion: Reusable Finger Clip: ± 2 digits Disposable 6000 Series: ± 2 digits Motion: Reusable Finger Clip: ± 2 digits Neonates No Motion: Reusable Finger Clip: ± 3 digits Disposable 6000 Series: ± 3 digits Pulse Rate Accuracy No Motion: 18–300 BPM Motion: 40–240 BPM Low Perfusion: 40–240 BPM Adults / Pediatrics No Motion: Reusable Finger Clip: ± 3 digits Disposable 6000 Series: ± 3 digits Motion: Reusable Finger Clip: ± 5 digits Low Perfusion: Reusable Finger Clip: ± 3 digits Disposable 6000 Series: ± 3 digits Neonates No Motion: Reusable Finger Clip: ± 3 digits Disposable 6000 Series: ± 3 digits Motion: Reusable Finger Clip: ± 5 digits Low Perfusion: Reusable Finger Clip: ± 3 digits Disposable 6000 Series: ± 3 digits Memory 70 hours (assuming continuous operation) Internal Power Battery: 7.2 volt NiMH battery pack Operating Life (fully charged battery): 16 hours minimum Storage Life: 21 days minimum Recharge Rate: 4 hours maximum Analog Outputs SpO2 Output Range: 0-1 VDC (0–100% SpO2), 1.27 VDC (out of track) Pulse Rate Output Range: 0-1 VDC (0–300 BPM), 1.27 VDC (out of track) Event Marker: 0 V (no event), 1 V (event occurred) Accuracy: ± 2% (SpO2), ± 5% (Pulse Rate) Load Current: 2 mA maximum
