Details

Zimmer ATS 1500 Features The Zimmer ATS 1500 is an automatic tourniquet which has been found useful in producing a bloodless operating field in a surgical procedure involving extremities. It is indicated to temporally occlude blood flow in patient’s extremities during a surgical procedure on those extremities. Indicated to temporally occlude blood flow in a patient’s extremities during surgical procedures on those extremities. Tourniquets have been found useful in producing a bloodless operating field in surgical procedures involving the extremities. Zimmer ATS 1500 Specifications Dimensions Height: 16.13 in (41 cm) Width: 8.75 in (22.3 cm) Depth: 7.1 in ( 17.9 cm) (Including 2 in clamp) Weight: 19.8 lbs (9 kg) General Line Voltage Rage: 105-130 VAC, 50/60 Hz Line Current: 485 mA RMS Max., 300 mA RMS nominal Input Power: 58 W max, 36 W nominal Power Cord Type: SJT, AWG 18, 13 ft. 2 in (4.01m) Power Plug Hospital grade, 3 prong straight blade, 15A Line Protection: 0.5A, 250V, 5 x 20 mm SLO-BLO fuse Cuff Pressure Range: 50-475 mmHg Pressure Accuracy: ± 5 mmHg (50-475 mmHg) Pressure Regulation: ± 6mm of set point Maximum Pressure: 475 mmHg (Nominal operation), 600 mmHg (internally limited) Time Alarm Set Ranges: 0-240 minutes ; 1 minute increments Timer Accuracy: 0.25% ± 1 second Battery Battery Type: Rechargeable, sealed lead acid, 12 VDC, 2.3 AH Battery Discharge Time: Unit will operate on battery power for 15 minutes (minimum with fully charged battery) Battery Recharge Time: 24 hours maximum
