Details

Steris OT 1000 Series Features The OT1000 Series Orthopedic Surgical Tables are mobile, power operated orthopedic tables. They provide flexible, easy-to-use, articulated posturing of the patient for reconstructive and reparative orthopedic procedures in a controlled, sterile operating room environment. The OT1000 Series Orthopedic Surgical Tables are designed primarily for hip and lower extremity procedures: hip pinning, ender nailing, intramedullary nailing of the femur, tibia and fibula surgery. Recommended patient population includes people up to 7 ft (2 m) and/or a body weight up to 500 lb (227 kg). Revolutionary Orthopedic Surgical Table with SWAN Technology for superior control and effortless movement Designed to increase productivity with Increased OR versatility, optimized imaging, improved safety Benefits for every member of the team: anesthesiologists, surgeons, OR Nurses Steris OT 1000 Series Specifications Dimensions Dimensions (W x L x H): 27.25 x 104.5 x 31 to 48” (692 x 2654 x 787 to 1219 mm) Patient weight capacity 500lb (227kg) Table Operating Weight Approximately 1000lb (454 kg) Power Power Consumption 70 W, typical; max. 2.2 kW with aux power sockets in use Power Source Battery/Electric-Powered Table Line power Input 100, 120, 220 or 230-240 Vac (Jumper Selectable), 1 Ø, 50/60 Hz, 4.0 Amp Environmental Operating: Temperature: 63 - 77°F (17 - 25°C); Relative Humidity (RH): 20 - 80%; Atmospheric Pressure: 700 - 1060 hPa Storage: Ambient Temperature: -40 - 158°F (-40 - 70°C) - Not to Exceed 15 Weeks; Relative Humidity (RH): 10 - 100% Non-Condensing; Atmospheric Pressure: 500 - 1060 hPa Table Configuration Power adjustable height, Trendelenburg/Reverse Trendelenburg, Lateral Slide and Lateral Tilt Functions Manual, adjustable head section Pendant Hand Control Mobile base with hydraulically operated self compensating floor locks SWAN Technology Table Motion Lateral Slide Motion: ± 4” (102 mm) from center Height Range: 31 to 48” (787 to 1219 mm) Patients up to 400 lb and 31 to 43” (787 to 1092 mm) Patients between 401 and 500 lb Trendelenburg Range: 15° Reverse Trendelenburg Range: 15° Tilt Range: 15° Head Section (Manual): DOWN: 30 or 75°
