More Sonosite Titan Pictures SonoSite Titan - Soma Technology, Inc.SonoSite Titan Ultrasound - Soma Technology, Inc.Titan Ultrasound - Soma Technology, Inc. Sonosite Titan Features Stationary and mobile usage. Point-of-care connectivity. Flexible, cost-effective paths that enable users to acquire new components and software applications. Sonosite Titan Specifications Titan System Specifications System weight: 7.7 pounds. System dimensions: 11.9" L x 10.9" W x 3" H. Integrated fully digital 8.4" (diagonal) TFT color Liquid Crystal Display. Mobile Docking System Mobile Docking System dimensions: 31.9" L x 22.6" W x adjustable height 33.2" to 45.1". Storage available for fully integrated printer, VCR or DVD. Optional connector for 3 transducers - selection by simple electronic switching. Optional 12.1" (diagonal) monitor. Imaging Modes 2D. Split screen. Zoom. Color power Doppler. M-Mode: 3 sweep speeds 1/2:1/2, 1/3:2/3 or full screen options. Pulsed wave (PW) Doppler. Continuous wave (CW) Doppler. Velocity based color flow Doppler. Duplex imaging 3 sweep speeds 1/2:1/2, 1/3:2/3 or full screen options. Tissue Harmonic Imaging. (THI) Transducers All transducers are lightweight with rapid, pinless connectors and feature a user selectable menu to adjust frequency settings to suit the patient’s size. 2D settings are Penetration, General and Resolution imaging. C60/5-2MHz broadband curved array for general purpose, abdominal and obstetric imaging. 2D, CPD, velocity color, PW Doppler. Biopsy guide available. ICT/8-5MHz broadband intracavitary transducer for obstetric and gynecologic imaging. 2D, CPD, DCPD, PW Doppler. Biopsy guide available. C11/8-5MHz broadband tightly curved array for neonatal and pediatric imaging. Applications include general imaging, abdominal, cardiac and neonatal heads. 2D, CPD, velocity color, PW and CW Doppler. C15/4-2MHz broadband tightly curved array. Applications include adult cardiology general imaging, abdominal. 2D, CPD, velocity color, PW and CW Doppler. L38/10-5MHz broadband linear array. Applications include small parts, breast, vascular, musculoskeletal & superficial imaging. 2D, CPD, velocity color, PW Doppler. Biopsy guide available. HST/10-5MHz broadband linear array. Applications include intraoperative, vascular & superficial imaging. 2D, CPD, DCPD, PW Doppler. C8/8-5MHz broadband intracavitary transducer for prostate imaging. 2D, CPD, PW Doppler. Biopsy guide available. L25/10-5MHz broadband linear array for venous access procedures. CPD. Biopsy guide available. Remapable Controls Soft keys to drive advanced features Delta key: user selectable functions can be assigned to the delta key for increased ease of use. System Parameters System dynamic range: up to 155dB. Frame rates up to 150Hz maximum acquisition, 60Hz internal video display. Image Storage and CINE Storage: High capacity using flash card. 64MB and 256MB ScanDiskTM. The number of images saved to the flash card vary depending on the card storage capacity. Cine: Review of up to 220 frame-by-frame images. Connect directly to a PC with SiteLink Image Manager software using a USB or ethernet cable from the system. Allows transfers of high resolution bitmap images. Software allows batch compression to JPEG on PC. Image transfer can be active while live scanning on TITAN system. Clinical Analysis Package OB Calculation Package - Obstetric package includes fetal biometry measurements via user selectable authors. Vascular Calculation Package - Vascular package includes Lt/Rt CCA, ICA, ECA, ICA/CCA Ratio, user defined ratio, angle correction, volume flow. Volume calculations via diameters. Cardiac calculation package. SonoCalc- IMT analysis PC-based package. Measurement Tools 2D Distance calipers - two sets Ellipse for area and circumference measurements. M-Mode Distance and time caliper set Heart rate. Doppler Velocity caliper - two sets. Power Operates via battery or AC power - from 1.5 up to 4 hours on fully charged battery, new battery life depends on the active functions used and keystrokes. Battery: Rechargeable lithium ion. AC: Via universal power adapter, 100-240 VAC, 50-60 Hz. Display Annotation Text and pictograms - User-selectable, application-specific text via function keys. Peripheral Connections Composite video output (NTSC/PAL) to video cassette recorder, video printer or external monitor. Connect to a PC via USB or ethernet to download high resolution bitmap images. S-video output. Ethernet output. RGB output. Connectivity DICOM print and storage class software. DICOM worklist.
