Details

GE MiniView 6800 Features: The OEC 6800 Mini C-Arm is the newest in the line of OEC Mini C Arms.The OEC 6800 is a perfect fit for sports medicine, orthopedics,and veterinary medicine.As the first Mini C-Arm to use 1K x 1K imaging and a touchscreen interface, the OEC 6800 provides many of the components of a full sized system at a fraction of the cost. GE MiniView 6800 Specifications: General Image Intensifier Diameter: 15, 10 cm (6, 4 inches) Maximum output at 120VAC: 0.16 mA @ 80 kVp Heat capacity: 7000 HU Fluoroscopic Mode: 0.045 Cooling: 3000 HU/min Physical Dimensions of C-ARM H x W x D of C-arm frame: 65 x 28 x 28 Vertical movement: 27 inches Free space; 13.8 inches Reverse position: Yes Rotation: 115 degrees Depth: 17.7 inches Pivot rotation: 220 degrees Panning movement: 230 degrees Monitor size: 16 inch Dual Monitors Hard Copy Option Thermal printer Dicom Compatible Yes Image Processing and Storage Max. # of images: 400 CP, 800 HP Frame integration: Yes Image matrix size: 1000 x 1000 x 16 Last Image Hold: Yes Video storage Digital memory PCMCIA drive, hard disk, floppy disk, SVHS VCR optional Power Consumption 100, 240 VAC; 6,4A Generator: High-frequency Abs control: kVp, A Kv range: 40 Ma range: 0.02-0.16 Snapshot function: Yes
