Philips PageWriter TC50 EKG Features The Philips PageWriter TC50 cardiograph gives you high-level features in a compact package with an attractive, large touchscreen.As your workflow needs evolve, you’ll find the system is scalable to grow with you, protecting your investment. Compatibility with industry-standard 802.11 wireless protocols enables secure wireless communication to quickly download patient information and send reports to your ECG management system. Quickly and intuitively attach patient lead wires using the anatomically designed patient interface module. Easily identify poor or missing electrode connections through color-coded lead traces and lead map. Efficiently review the full ECG report on the large 10˝ touchscreen before printing to save time and paper. Philips PageWriter TC50 EKG Specifications Dimensions Height: 5.1 In (13 cm) Width: 12.2 In (31 cm) Depth: 15.9 In (40.5 cm) Weight: 19.8 lbs. (9 kg) Power Voltage: 9.0 to 12.6 VDC. Current: 6.0 A max per battery (continuous). Power: 35 to 44 W max per battery (continuous); 54 W max per battery (2-second peaks). Operating Capacity: 45 minutes of continuous Rhythm printing, or a maximum of 237 individual sheets of ECG recording paper. Less than five hours if cardiograph is in Standby (not in active use) to at least 95% capacity; Less than eight hours if the cardiograph is in active use to at least 95% capacity. Display 800 x 600 Pixel Resolution 8.3 x 9 In ( 21.1 x 15.8 cm) Color Liquid Crystal Touch Screen Backlit Screen ECG Acquisition Auto ECG (12 leads standard; up to 16 leads optional) Rhythm ECG (12 leads standard; up to 16 leads optional) Disclose (12 leads standard; 16 leads optional) Patient Interface Module Signal Acuisition 8,000 samples per second per electrode/lead for standard 12 or up to 16 leads. Sampling Rate 500 samples per second per electrode/lead. 2 bit A/D conversion provides down sampled 5μV resolution, 500 samples per second measurement with no channel to channel skew Auto Frequency Response 0.05-150 Hz, 0.15-150 Hz, 0.5-150 Hz 0.05-100 Hz, 0.15-100 Hz, 0.5-100 Hz 0.05-40 Hz, 0.15-40, 0.5-40 Hz
