Nellcor OxiMax N-600x Features The Nellcor OxiMax N-600x pulse oximeter is indicated for the continuous noninvasive monitoring of functional oxygen saturation of arterial hemoglobin (SpO2) and pulse rate. The N-600x is intended for use with neonatal, pediatric, and adult patients who are well or poorly perfused, in hospitals, hospital-type facilities, intra-hospital transport, and home environments. Simple, intuitive operation and easy-to-see display with dimmer and contrast adjustment. Compatible with the complete family of OxiMax Pulse Oximetry Sensors. Three display options: plethysmographic waveform, large numerics, and customizable real-time trend. On-screen quick guide provides instant help to assist caregivers with monitor operation. Convenient selection of adult or neonate alarm limits, and user-configurable power-on settings. User-selectable fast-averaging mode (2-3 seconds) to more precisely track rapidly changing saturations. Nellcor OxiMax N-600x Specifications Dimensions Height: 3.3 In (8.4 cm) Width: 10.4 In (26.4 cm) Depth: 6.8 In (17.3cm) Weight: 5.8 lbs (2.6 kg) Performance Measurement Range SpO2: 1% to 100% Pulse Rate: 20 to 250 beats per minute (bpm) Perfusion Range: 0.03% to 20% Accuracy Tolerance Saturation Adult: 70 to 100% ±2 digits Neonate: 70 to 100% ±3 digits Low Perfusion: 70 to 100% ±2 digits Pulse Rate Adult and Neonate: 20 to 250 bpm ±3 digits Low Perfusion: 20 to 250 bpm ±3 digits Power Power Requirements: Rated at 100 to 120 volts AC (nominal 120 VAC) or 220 to 240 volts AC (nominal 230 VAC), 20 volt/amps to be compliant with IEC 60601-1 sub-clause 10.2.2. Fuses Quantity: 2, 0.5 A, 250 volts, slow-blow, IEC (5 x 20 mm). Battery Type: Lead-acid Voltage: 6 Volts DC Recharge: 8 hours with N-600x turned off 12 hours with N-600x turned on Shelf Life: 4 months, new fully-charged battery (when monitor is placed in “Shelf-mode” by qualified service personnel using the procedures indicated in the N-600x Service Manual) After 4 months storage in “Shelf mode”, the N-600x will run for 33% of stated battery life
