Drager SCIO Features Drager Scio gas measurement modules deliver precise inspiratory and expiratoryvalues for O2, CO2, and anesthetic agents such as N2O, enflurane, halothane,isoflurane, sevoflurane and desflurane. Drager Scio gas measurement modules deliver precise inspiratory and expiratoryvalues for O2, CO2, and anesthetic agents such as N2O, enflurane, halothane,isoflurane, sevoflurane and desflurane. In combination with Drager Infinity monitors, MAC values for anesthetic agents aredisplayed, helping to avoid under- and overdosage The user can maintain optimal gas concentrations while making sure that ventilation isadequate There is the option to measure inspiratory and expiratory O2 concentrations using aparamagnetic oxygen sensor Comes equipped with the new WaterLock 2 water trap. The 2 m pores of itsdual hydrophobic membrane design let gases and water vapor pass freely withminimal pressure gradients while effectively preventing microbial contamination andcondensation. Drager SCIO Specifications Dimensions Size: 11.5 cm x 19.0 cm x 27.0 cm (4.8 in x 7.5 in x 10.5 in) Weight: 2.9 kg (6.4 lbs) w/o O2 sensor 3.2 kg (7.0 lbs) w O2 sensor Physical Specification Power supply: 100 to 240 V ~ 50/60 Hz Device noise emission: ≤45 dB(A) Device interfaces: 1x RS 232 (MEDIBUS protocol) Ambient conditions Temperature: 10 to 40°C (50 to 104°F) Ambient pressure: 700 to 1,100 hPa (10.2 to 15.9 psi), Equivalent to 3,000 m (9,843 ft) height Measurement specification O2 range:0 to 100 vol.% O2 Accuracy: ±(2.5 vol.%, + 2.5% rel.) O2 Rise Time: <500 ms CO2 Range: 0 to 10 vol.% CO2 Accuracy: ±(0.43 vol.% + 8% rel.) CO2 Rise Time: <300 ms N20 Range: 0 to 100 vol.% N2O Accuracy: ±(2 vol.% + 8% rel.) N2O Rise Time: <300 ms Anesthetic Agent Range: 0 to 8.5 vol.% (isoflurane and halothane), 0 to 10 vol.% (sevoflurane and enflurane), 0 to 20 vol.% (desflurane) Anesthetic Agent Accuracy: ±(0.20 vol.% + 15% rel.) Anesthetic Agent Rise Time: <350 ms, <450 ms (halothane) Sepiratory Rate Range: 0 to 100/min Sepiratory Rate Accuracy: 0 to 60/min: ±1/min, >60/min: not specified
