Covidien Capnostream 20p Features The Capnostream™ 20p patient monitor is built on a legacy of proven performance. For nearly two decades, clinicians have relied on Microstream™ technology for an accurate, continuous view of ventilation adequacy on intubated and non-intubated patients, from neonate to adult. The new Capnostream™ 20p monitor, with the Apnea-Sat Alert feature, alerts caregivers to repetitive patterns of apneas and oxygen desaturation, revealing a more complete picture of a patient’s respiratory status. Supports current standards of care by providing etCO2 and SpO2 measurements. The Capnostream™ 20p patient monitor with Microstream™ includes Smart Alarm Management™ Integrated Algorithms, a suite of algorithms proven to reduce alarms and simplify the use of patient monitoring to enhance patient safety and improve clinical efficiency. Screens out low amplitude ‘non-breath’ etCO2 excursions like, talking, crying or snoring. Reduces clinically insignificant alarms. Alerts clinicians to clinically significant changes in pulse oximetry. IPI algorithm presents one value that demonstrates real-time respiratory status based on etCO2, RR, PR and SpO2. Tracks and reports apneas per hour and oxygen desaturation index, and provides the data in trend reports. Compatible with central monitoring systems and interfaces with nurse call systems and electronic medical records. Provides convenient bedside documentation. Covidien Capnostream 20p Specifications Dimensions Unit Dimensions: 167 mm. (h) x 220 mm. (w) x 192 mm. (d); (6.6 in. (h) x 8.7 in. (w) x 7.6 in. (d)) Unit Weight: 3.6 kg. 7.94 lb. Display: 12.1”/30.7 cm diagonal LCD; (NTSC or PAL) with chemically etched glass layer Packaged Dimensions 315 mm. (h) x 340 mm. (w) x 285 mm. (d); 12.4 in. (h) x 13.4 in. (w) x 11.2 in. (d) Power Power Supply Input Voltage 100-240 V, 50/60 Hz, ± 10%. Microstream Capnography Units: mmHg, kPa or Vol%. Measurement range: etCO2, FiCO2 0-150 mmHg. Respiratory Rate: 0 bpm-150 bpm. Resolution: 1 mmHg. Accuracy (±SD): etCO2, FiCO2 0-38 mmHg ± 2 mmHg. 39-150 mmHg ± (5% of reading + 0.08% for every 1 mmHg above 38 mmHg). Respiratory rate: 0-70 bpm ±1 bpm, 71-120 bpm ±2 bpm, 121-150 bpm ±3 bpm. Flow rate: 50 ml/minute, flow measured by volume. Waveform sampling: 50 millisecond intervals. Response time: 2.95 second (typical). Initialization time: 40 second (typical). Calibration interval: Initial calibration after 1,200 operating hours, then annually or after 4,000 operating hours, whichever comes first. Nellcor Pulse Oximetry Measurement range 0-100%. Accuracy Adult mode: SpO2 range 70%-100% ± 2 digits; SpO2 range 0-69% unspecified. Neonate mode: SpO2 range 70%-100% ± 3 digits; SpO2 range 0-69% unspecified. Pulse rate: Range: 20-250 BPM; Accuracy: ± 3 BPM; Sat Sec Range: 10, 25, 50, 100.
