Mindray Datascope AS3000 Features The Mindray Datascope AS3000 is a continuous flow anesthesia system which offers manual or automatic ventilation, easily adjustable fresh gas delivery, anesthetic agent delivery, ventilation monitoring, convenient ergonomics, and state-of-the-art safety systems. Multiple ventilator modes including: Pressure Controlled Ventilation (PCV), Pressure Support Ventilation (PS), Synchronized intermittent mandatory Ventilation (SIMV) and Volume Controlled Ventilation (CMV). The warmed breathing system (35°C) virtually eliminates internal condensation. The auxiliary O2 / air flowmeters provide a built-in method of regulating O2 concentration. Remote, dedicated 10.4” color display, adjustable for maximum visibility of ventilator information. Mindray Datascope AS3000 Specifications Dimensions Height: 54.3 In (138cm) Width: 25.6 In (65 cm) Depth: 27.2 In (69 cm) Weight (Without vaporizers or gas cylinders): 326 lbs (148 kg) Drawers Number of Drawers: 3 Equal Size Power Main Power Supply: 100 to 240 VAC, 50/60 Hz, 10 A Current Input: 120 VAC - 10 A (2 A for AS3000, 8 A for auxiliary outlets) Power Consumption: Less than 200 VA (not including auxiliary outlets) Main Fuse: 2 x 10A Battery Battery: 2 x 12 V Sealed Lead Acid Battery Run Time: 45 minutes minimum Battery Charge Time: 8 hours maximum Ventilator Ventilation Modes: CMV (Volume), PCV (Pressure Control), SIMV (Synchronized Volume), Pressure Support, Manual, and Spontaneous Patient Types: Adult and Child Tidal Volume: 40 - 1400 ml Child: 40 - 400 ml (± 17% or at least 20 ml) Adult: 300 - 1400 ml (± 15% or at least 50 ml) Pressure delivery range: 5 - 70 cmH2O Manual and PCV modes 3 - 80 cmH2O PS and SIMV modes Anesthetic Gas Scavening System (Low Flow) Flow Range: 25 to 50 l/min Maximum Constant Flow Before Spillage Occurs: 50 l/min Particle Filter: Replaceable
