Details

GE OEC 9900 Elite Features: Precision imaging Dynamic Range Management (DRM) for uncompromised image quality. Touchscreen controls Proprietary "no mask" or Motion Tolerant Subtraction (MTS) technique produces vascular images not previously possible on a mobile platform. Capabe to perform a complete extremity run-off with a single injection and single run. Unique X-ray tube and cooling system that allows for full-resolution imaging for longer periods of time. HD flat panel monitors on an articulating arm allow comfortable viewing of precise images. Remote service connectivity to enable system performance diagnostics. 1k x 1k high resolution imaging technology on a mobile system. GE OEC 9900 Elite Specification: Generator 60 kHz high frequency. 15 kW full-wave. Up to 120 kVp. Up to 75 mA for radiographic film exposure. Continuous high level fluoro up to 20 mA. Pulsed fluoro mode. Pulsed fluorography mode up to 40 mA. Digital spot up to 75 mA. Full power from outlet: 50 Hz or 60 Hz. 120V-12A or 240V-10A. X-Ray Tube Rotating anode X-ray tube. Focal spots: 0.3 mm and 0.6 mm. Anode heat capacity: 300,000 HU. Anode cooling rate: 85,000 HU/min. Housing heat capacity: 1,600,000 HU. Standard housing cooling 15,000 HU/min. Passive housing cooling system: 22,500 HU/min. (Standard on 12 inch (31 cm) I.I. systems. PreView™ Collimator On-screen collimator position indication. PreView™ iris collimator. PreView™ Tungsten rotatable double leaf collimator. Adjusts collimators without X-ray exposure. Fluoroscopy Mode Focal spot: 0.3 mm. kVp range: 40 – 120 kVp. mA range: 0.2 – 10 mA normal mode. mA range: 1.0 – 20 mA HLF. (high level fluoro.) Auto and manual fluoro modes. Continuous, one-shot or pulsed operation. AutoTrak™ ABS varies mA, kVp, camera gain. Pulsed Fluoroscopy Mode Focal spot: 0.3 mm. kVp range: 40 – 120 kVp. mA range: 0.2 – 10 mA. Pulse rate: 1, 2, 4, or 8 pulses per second. Pulse width: 25 or 50 milliseconds. AutoTrak™ ABS, mA, kVp, camera gain. Reduces X-ray dose to patient and operator. High Level Pulsed Fluoro Vp range: 40 – 120 kVp. mA range: 1 – 40 mA. Pulse width: 25 or 50 milliseconds. Pulse rate: 1, 2, 4, or 8 pulses per second. AutoTrak™ ABS, mA, kVp, and camera gain. Digital Spot Mode kVp range: 40 – 120 kVp. mA range: Up to 75 mA. Automatic exposure termination and automatic image save. Video Camera High resolution 1k x 1k CCD camera. Full frame capture. Motorized rotation. On-screen orientation indicator. (real-time feedback without fluoro.) Left-right image reversal. Top-bottom image reversal. Video Monitors Dual 18” (46cm) display anti-glare, LCD flat panel monitors mounted on an articulating arm. 22” horizontal travel. 7° up/10° down. Monitors viewable from all four sides of workstation. Horizontal and vertical viewing angle 170°. 700 CD/M2 maximum brightness. Touch screen system control. 1280 x 1024 high resolution monitors. Ambient room-light compensation. Integrated color monitor for display of VGA, DVI, DVI-D, S-VHS. C-Arm Dimensions Height: 69.7 / 87.7 in. (1770 / 2228 mm.) Width: 33.5 in. (851 mm.) Length: 77.8 in. (1976 mm.) Weight: 610 lbs. (277 kg.)
