GE LOGIQ S7 Features The used GE Logiq S7 Pro/Expert ultrasound machines are the mid-range options in GE’s “Signature” series of compact, lightweight ultrasound systems. The refurbished GE Logiq S7 is available in Pro and Expert models. Both include some of GE’s high-end imaging technologies such as Elastography, Flow Quantification, contrast imaging, volume imaging, SRI-HD, CrossXBeam and Scan Assistant. It has a 19″ LCD display on a fully articulating arm and hight-and-swivel adjustable user interface. Optional features make this a shared service ultrasound machine with cardiac and stress echo modules. Volume obstetrical 3D/4D is also available as an option. The Expert model runs extra transducers and has a height-adjustable keyboard. CrossXBeam 3D/4D Volume obstetric imaging 2D/3D/4D modes PW/Color/Power Doppler (CW Doppler as option) Anatomical M-Mode ECG module with CW upgrade SRI HD High Definition Speckle Reduction Imaging CrossXBeam 19″ LCD monitor GE LOGIQ S7 Specifications Dimensions Height Standard: 1750 mm (68.9 in) Tall: 1115 mm (43.9 in) Width Keyboard: 500 mm (19.7 in) Caster: 620 mm (24.4 in) Depth Maximum: 856 mm (33.7 in) Caster: 790 mm (31.1 in) Weight (no Peripherals): 90 kg/198 lbs Design 4 active probe ports, 1 non-imaging Integrated HDD and DVD-R/W On-board storage for peripherals Integrated speakers Probe holders Gel holder/warmer Front and rear handles Power Voltage: 100-120 Vac or 220-240 Vac Frequency: 50/60 Hz Power consumption maximum of 900 VA with peripherals Image Memory 84 MB of Cine Memory Selectable Cine Sequence for Cine Review Prospective Cine Mark Measurements/Calculations and Annotations on Cine Playback Scrolling timeline memory Dual Image Cine Display Quad Image Cine Display Cine Gauge and Cine Image Number Display Cine Review Loop Cine Review Speed
