Zoll X Series Features Weighing under 12 pounds, the Zoll X Series is full featured and designed to be effective for all patients, including neonates. Transporting a critically ill patient through the hospital requires a lightweight device with extensive monitoring capabilities. And that’s exactly what you get with the X Series®, plus defibrillation and real-time CPR feedback in one compact device. Capnography Pulse oximetry Three invasive pressures Two temperature channels Non-invasive blood pressure Zoll X Series Specifications General Weight: 11.7 lbs. (5.3 kg) with battery and paper Dimensions: 8.9 in (22.6 cm) x 10.4 in (26.4 cm) x 7.9 in (20.1 cm) Enclosure Protection Solid Foreign Object: IEC 60529, IP5X Water: IEC 60529, IPX5 Operating Conditions Temperature: 0 to 50°C Humidity: 15 to 95% RH (non-condensing) Vibration: MIL-STD 810G, Method 514.6, 4.4.2 Procedure II EN ISO 9919 (per IEC 60068-2.64) EN 1789 for ambulance. RTCA/DO-160G (multiple helicopter frequencies) Shock: IEC 60068-2-27, 100g, 6 ms half sine Drop: EN 1789, 30-inch functional drop, IEC 60601-1, tested at 2 meters Altitude: -170 m to 4572 m (-557 feet to 15,000 feet) Monitor / Display Size: 6.5 in (16.56 cm) diagonal Input: 3-lead, 5-lead, or 12-lead patient cable, paddles, or multifunction electrodes Type: Color LCD, 640 x 480 pixels, 800 MCD Sweep Speed (user selectable): 25 mm/sec or 50 mm/se Lead Selections: Paddles (Pads), I, II, III, AVR, AVL, AVF, V1-6 Frequency Response (user selectable) 0.67 – 20 Hz Limited mode 0.67 – 40 Hz Monitor mode 0.25 – 40 Hz Filtered diagnostic mode 0.05 – 150 Hz Diagnostic mode Defibrillator Waveform: Rectilinear Biphasic™ Energy Selections: 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 15, 20, 30, 50, 70, 85, 100, 120, 150, 200 joules Energy Display: Display indicates selected and delivered energy Charge Time: Less than 7 seconds with a new, fully charged battery Charge Controls: Front panel and on apex paddle Pads/Paddles: Hands-free pads and external adult and pediatric paddles. Adult paddles slide off to expose pediatric paddles. Synchronized Mode: Synchronizes defibrillator pulse to patient’s R wave. “SYNC” message displayed on monitor and markers shown on both monitor and recorded ECG. Meets Clause 104 of AAMI DF80.
