Drager Fabius GS Anesthesia Machine

Drager Fabius GS Anesthesia Machine

Brand:   Drager
Condition:   SellerRefubrished
Drager Fabius GS Anesthesia Machine
Quantity:
Have a question? Feel free to Ask a question
Please Sign In To Inquire Price
If you just logged in, please refresh the page

Details

Dräger Fabius GS Features: Proven Ventilation Versatility Electronic Gas-Flow Measurement Compact, Convenient Breathing System Intelligent Cable Management Dräger Fabius GS Specifications Weight: 224 lbs. (101.6 kg) (base unit without vaporizers or cylinders.) Dimensions: (W) 89.5 cm x (H) 130 cm x (D) 82 cm (35.2 x 51.2 x 32.3 inches) Power Supply: 100 - 240 VAC, 50/60 Hz, 2.3 A max. Battery (supports ventilator and monitor) > 45 min. Ventilator: E-vent Electronically controlled, electrically driven. Operating Modes Standard: Manual/Spontaneous. Volume Control (IPPV). Options: Pressure Control. (PCV) Pressure Support. (PS) Synchronized Volume Controlled Ventilation w/PS. (SIMV/PS) Breathing Frequency: 4 to 60 bpm. Max. Minute Volume (MV): 25 L/min. PEEP: 0 - 20 cmH2O. Inspiration / Expiration Ratio: (Ti:Te) 4 : 1 to 1 : 4. Pressure Limiting (Pmax): 15 - 70 cmH2O. Tidal Volume (Vt): 20 - 1400 mL in Volume Control. 20 - 1100 mL in SIMV/PS. Inspiratory Pause (Tip:Ti): 0 - 50 . SIMV Inspiratory Time(Tinsp): 0.3 - 4.0 sec. Inspiratory Pressure (Pinsp): PEEP + 5 to 65 cmH2O. Inspiratory flow (InspFlow): 10 - 75 L/min in Volume and Pressure Control. 10 - 85 L/min in Pressure Support. Pressure Support Level (Δ PPS) PEEP: + 3 to 20 cmH2O Min. Frequency for 3 - 20 bpm and “ OFF ”. Apnea-Ventilation: ( Freq. Min.)Trigger 2 - 15 L/min. Safety functions: Sensitive Oxygen Ratio Controller (S-ORC) guarantees a minimum O2 concentration of 23% in an O2/N2O mixture. N2O cut-off if O2 fresh gas valve is closed or if O2 flow is less than 0.2 L/min. Safety functions: Sensitive Oxygen Ratio Controller (S-ORC) guarantees a minimum O2 concentration of 23% in an O2/N2O mixture. N2O cut-off if O2 fresh gas valve is closed or if O2 flow is less than 0.2 L/min. Audible and visual (flashing red LED)indication in case O2 pressure drops below 20 psi (1.38 bar) ± 4 psi (0.27 bar). In case of electricity and battery failure, manual ventilation, gas delivery and gent delivery are possible. Positive pressure relief valve opens at 75 ± 5 cmH2O. Negative pressure relief valve opens at - 7.5 to - 9 cmH2O. Range of fresh gas flow indicators: 0.00 to 12.0 L/min. Total fresh gas flow meter: 0 to 10 L/min, calibrated with a mixture of 50 % O2 and 50 % N20 mixture. O2 flush at 87 psi (6 bar): max. 75 L/minat 41 psi (2.8 bar): min 25 L/min. Vaporizer Mount: Dräger or SelectatecR mount. Monitoring: Continues monitoring of inspiratory O2 concentration (can be switched off by Service) breathing frequency, tidal volume, minute volume, mean or plateau pressure, peak airway pressure as well< as PEEP. In addition, all fresh gas flow information is displayed as virtual flow tubes. Serial interface: 1 x RS 232 (standard); 1 x RS 232. (option)
