Details

Valleylab Force 2 Features High Power Digital ESU. High performance capabilities in a multipurpose generator Provides flexibility through varying degrees of homeostasis Operator can choose one of three preset modes: simultaneous independent coagulation, low voltage coagulation and Valleylab REM safety, which substantially reduces the risk of patient burns at the return electrode site Valleylab Force 2 Specifications Weight 23 lbs. (10.4 kg) Dimensions 8"H x 13"W x 21"L (20 x 33 x 53 cm) Output Characteristics Pure Cut: 300 watts Blend 1: 250 watts Blend 2: 200 watts Blend 3: 150 watts Coag: 120 watts Low Voltage Coag: 99 watts Bipolar: 70 watts Output Waveform Cut: 500 kHz sinusoid Blend 1: 500 kHz bursts of sinusoid at 50% duty cycle recurring at 31 kHz Blend 2: 500 kHz bursts of sinusoid at 37.5% duty cycle recurring at 31 kHz Blend 3: 500 kHz bursts of sinusoid at 25% duty cycle recurring at 31 kHz Coag: 500 kHz damped sinusoidal bursts with repetition frequency of 31 kHz Low Voltage Coag: 500 kHz bursts of sinusoid at 25% duty cycle recurring at 31 kHz Bipolar: 500 kHz sinusoid, unmodulated Input Power Source Max.Current: Idle: 0.4 A; Cut: 6 A; Coag: 3 A; Bipolar: 1.5 A Max. Power: Idle: 50 W; Cut: 700 W; Coag: 300 W; Bipolar: 180 W
