The Amplivox 170 is a stylish, cost-effective screening audiometer offering both automatic and manual audiometry. Features and Benefits Improved Use The Amplivox 170 is ideal for occupational health and primary care audiometric requirements. Upon test completion, results can be printed with the optional Sanibel Infra-red External Printer (Printer cable is required for optional external printer), saved in memory for future use, recorded manually or transferred to a PC installed with Amplivox audibase software for electronic storage and statistical analysis of audiogram results. Totally portable Lightweight and compact, the Amplivox 170, weighs just 1.6 pounds and is totally portable. Ideal for both desktop and mobile needs Ergonomic Design Laid out in an ergonomic manner, the control panel is clear, easy to read and very easy to use with all settings and results displayed on the backlit display. The Amplivox 170 is designed and manufactured to conform with the relevant international audiometric and safety standards.
Materials Included Amp 170 Automatic & Manual Audiometer 1 Audiometric Headset 1 Patient Response Switch (50) Audiogram Cards 1 Power Adapter 1 CD Software User Manual
Technical Specifications Output/Input Data Outputs: Left AC, Right AC Frequency range (Hz): 125, 250, 500, 750, 1K, 1K5, 2K, 3K, 4K, 6K, 8K Frequency accuracy: <1% Distortion: <2% Output level range (AC): -10dBHL to 100dBHL (max) Output level accuracy: Within 3dB Output level step size: 5dB Test modes: Automatic and Manual Internal memory: 12 complete tests Designed Printer: High speed portable thermal printer Physical Data Graphic display: 2 lines of 24 characters (backlit) Power (Mains): 100-240V ac 50/60 Hz Dimensions: Length:10.5” Width: 7” Height: 2.75” Weight: 1.6 lbs Standards Safety: EN60601-1 EMC: EN60601-1-2 Audiometric: IEC 60645-1 ANSI S3.6 CE Mark: Complies to EU Medical Device Directive
