CSL-4U Examination Slit Lamp
Details
Combining the highest quality standards with the best value in the market, The CSL-4U Slit Lamp is a perfect addition to any office. Its stereoscopic converging microscope yields a clear, sharp image that grants the operator a clear field of view. The halogen bulb provides consistent lighting for observation and optimum color rendition. This classic Slit Lamp is popular world-wide for its excellent optics and user-friendliness. SL 4USOLO 800pxFeatures Include: Converging stereoscope HS Style 1x,1.6x objective magnification Two-step objective toggle magnification 10x eyepiece magnification Slit width: 0-14mm Slit length: 1-14mm Low/High illumination modes Digital imaging available
Tech Specs
Magnification Field of View Diameter 1x ,10x =18mm 1.6,16x=14.5mm PD Adjustment 55-82mm Diopter Adjustment +5D to -8D Slit Angle 0-180° Slit Inclination 5°, 10°, 15°, 20° Aperture Diameter 14mm, 10mm, 5mm, 3mm, 2mm, 1mm, 0.2mm Chin Rest Range 80mm Vertically Fixation Target Red LED Illumination 6v 20W Halogen Power 110/220V 50/60Hz 58VA Base Movement F/B= 90mm, L/R =100 Fine= 15mm, Vertical= 30mm Ship Weight 51lbs
