Details

Opto Ilunas Surgical Microscope Binoculars – Converging, inclinable 200° Eyepiece Magnification – 12.5x Pupillary Distance Range – 48- 78mm Refracative Correction – ±6D Optical Correction – Apochromatic with residual aberration correction Field of View – 10-60mm Magnification Range – 5- 30x (200mm objective lens), 6 – 33x (175mm objective lens) Focal Length – 200mm – Standard – Optional: 175mm, 250mm, 300mm, 350mm, 400mm Fine Focusing – Motorized 40mm range with automatic centering Built-in Filters – Anti UV and IR green, blue and optional yellow Light Bulb – 21v, 150w halogen Illumination Field – 60mm Illumination Intensity – 90,000 lux Bulb Swap Mechanism – Semi-Automatic XY Translation System – Motorized movement range 45x45mm with automatic centering Foot Controls – Focus, zoom, XY translation, light intenssity, light on/off Brake System – Foot actuated locking wheels Handgrips – Removable & Sterlilzable Arm Type – Gas adjustable center lever pantographic Video Camera Power Supply – Integrated 12v DC Operating Voltage – Auto ranging 90-240VAC, 50/60Hz Power Consumption – 200 VA Weight – 130kgs (287lbs) not including accessories Microscope Dimensions Base 700mmx 700mm, Height 1640mm, Width (at full span) 1400mm
