Details

Zoll M Series CCT Features The M Series CCT is designed with several user selectable features that allow operators to configure the device according to their protocols and local requirements. This manual describes the configuration options and how to change them. This manual also lists the configurable features, options and default settings. Some features are available to manual mode operators only. Superior defibrillation Superior pacing Advisory capabilities Transport-ready design Easy-to-read display Full range of parameters for full range of patients Flexible color display Quick, easy connections Zoll M Series CCT Specificaitons Defibrillator Waveform ZOLL Rectilinear Biphasic. Energy Selection: Selectable at 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 15, 20, 30, 50, 75, 100, 120, 150, 200 joules. (Delivered into 50 ohm load.) Charge Time: Less than 6 seconds with a new fully charged battery (first 15 charges to 200J.) Depleted batteries will result in a longer defibrillator charge time. Energy Display: Monitor display indicates both selected and delivered energy. Synchronized Mode Synchronizes defibrillator pulse to patient’s R-wave. “SYNC” message displayed on the monitor. Marker on display and recorder paper identifies R-wave discharge point. Advisory Function: Single analysis or programmable auto re-analyze x3 with programmable auto energy level selection, screen prompts, and voice prompts. Charge Controls: Control on apex paddle and on device front panel. Paddles: External anterior/anterior adult and pediatric. Adult paddles slide off to expose pediatric paddles. Multi-Function Electrode (MFE) Pads: Specifically designed adult anterior/posterior pre-gelled ZOLL MFE Pads, and Multi-Function stat•padz™ packaged in pairs. Built-In Defibrillator Tester: Tests defibrillator energy output and continuity of universal cable and paddles; documented on PCMCIA card and strip chart. Defibrillation Advisory Evaluates electrode connection and patient ECG to determine if defibrillation is required. Shockable Rhythms: Ventricular fibrillation with amplitude > 100 μV and wide complex ventricular tachycardia with rates greater than 150 bpm. Multi-Function Electrode Impedance Measurement. Range 0-250 ohms Display Screen Type Color LCD. Screen Size: 6.5 inches (16.5 cm) diagonally. Sweep Speed: 25 mm/sec. Viewing Time 4 seconds. Traces: 3. Information: Heart Rate, Lead/Pads, Alarm On/Off, Advisory Functions and Prompts, Defibrillator Test Function, Error Corrections and Faults, Code Markers, Alarm Selection and Limits, Delivered Energy, SpO2, Pacer Functions, EtCO2, NIBP, Invasive Pressures (2), Temperature (2). ECG Monitoring Patient Connection 3-lead ECG cable, 5-lead ECG cable, 12 lead cable, paddles or MFE Pads. Input selection on the front panel. Input Protection: Fully defibrillator protected. Special circuit prevents distortion of ECG by pacer pulse. (Pacer version only.) Implanted Pacemaker Spike Display: Dedicated circuitry detects most implanted pacemaker spikes and provides standard display marker of spike on ECG trace. Bandwidth: 0.5-40 Hz (-3 dB) standard/0.05-150 Hz diagnostic. Lead Selection: Displayed on monitor. ECG Size: 0.5, 1, 1.5, 2, 3 cm/mV - display on monitor. Heart Rate: Digital display 0-300 bpm ±5%. Heart Rate Alarm: On/Off displayed on monitor. User-selectable, tachycardia 60- 280 bpm, bradycardia 20-100 bpm
