Valleylab Force 1C Features The Force 1C generator features a compact design suitable for the requirements for outpatient and office-based surgery, and the performance requirements for a full range of inpatient general surgery applications. Outpatient procedures to full range surgical applications Monopolar and Bipolar outputs Audible and visual alarms Valleylab Force 1C Specifications Dimensions Dimensions: 6 × 11 × 17 inches (15 × 28 × 43 cm) Weight: 5 lbs (6.8 kg) Output Waveform Cut: 516 kHz sinusoid Blend 1: 516 kHz of sinusoid at 70% duty cycle recurring at 31 kHz Blend 2: 516 kHz bursts of sinusoid at 45% duty cycle recurring at 31 kHz Blend 3: 516 kHz bursts of sinusoid at 20% duty cycle recurring at 31 kHz Coag: 516 kHz damped sinusoidal bursts with a repetition frequency of 31 kHz Micropolar: 516 kHz sinusoid, unmodulated Output Characteristic Cut: 2400 Max. (open circuit) P-P voltage; 300 Rated Load ohms; 200 Nominal Power at rated load watts; 1.8 @ 100 W Crest Factor at rated load typical Blend 1: 2800 Max. (open circuit) P-P voltage; 300 Rated Load ohms; 175 Nominal Power at rated load watts; 2.7 @ 100 W Crest Factor at rated load typical Blend 2: 3200 Max. (open circuit) P-P voltage; 300 Rated Load ohms; 150 Nominal Power at rated load watts; 3.3 @ 100 W Crest Factor at rated load typical Blend 3: 3600 Max. (open circuit) P-P voltage; 300 Rated Load ohms; 125 Nominal Power at rated load watts; 4.6 @ 100 W Crest Factor at rated load typical Coag: 5200 Max. (open circuit) P-P voltage; 300 Rated Load ohms; 75 Nominal Power at rated load watts; 8.0 @ 50 W Crest Factor at rated load typical Micropolar: 900 Max. (open circuit) P-P voltage; 100 Rated Load ohms; 50 Nominal Power at rated load watts; 1.8 @ 40 W Crest Factor at rated load typical Power (Max. operating range: 85-135 or 170-270 VAC; Nominal operating range: 110-120 or 220-240 VAC) Idle: 0.5 A Max. Current; 60 W Max. Power Cut: 5.0 A Max. Current; 600 W Max. Power Coag: 3.0 A Max. Current; 400 W Max. Power Micropolar: 2.0 A Max. Current; 180 W Max. Power Line Regulation Between 85-135 volts or 170-270 volts input, output power into nominal load will vary no more than 20% or 5 watt, whichever is greater REM Contact Quality Mon. Measurement frequency: 140 kHz ± 20 kHz. Measurement current: 3.0mA, maximum Low Frequency Leakage Source current nominal polarity, intact chassis ground: <10 µA, ground open: <50 µA. Source current reverse polarity, ground open: <50 µA. sink current, 135 VAC applied, all inputs: <20 µ A. Chassis source current, ground open: <100 µA Low Frequency Leakage Source current nominal polarity, intact chassis ground: <10 µA, ground open: <50 µA. Source current reverse polarity, ground open: <50 µA. sink current, 135 VAC applied, all inputs: <20 µ A. Chassis source current, ground open: <100 µA Micropolar RF leakage current: <150 mA. Monopolar RF leakage current: <150 mA
