Details

More Stryker Smart Pump Pictures Stryker Smart Pump - Soma Technology, Inc.Stryker Smart Pump Tourniquet Cuffs - Soma Technology, Inc.Stryker Smart Pump on Stand With Printer - Soma Technology, Inc. Stryker Smart Pump Features The Stryker SmartPump is a dual channel tourniquet pump. It is designed for use by qualified medical personnel to temporarily impede blood flow in a patient’s extremity in order to create a blood-free surgical zone. Its dual channel design supports single cuff, bilateral and Bier Block procedures, and allows for simultaneous surgery of both an upper and lower limb. Each cuff’s unique pressure and time settings are displayed, controlled, and monitored independently. The SmartPump uses single port cuffs. The procedure timer and cuff target pressure may be set using simple, intuitive steps. Control buttons are clearly identified. Inflation is initiated by pressing the Inflate button. Deflation is initiated by pressing and holding the Deflate button for 1.5 seconds. The large, bright, backlit LCD display shows total elapsed cuff inflation time and cuff pressure (mmHg). The displayed time format is user selectable: minutes or hours and minutes. Stryker Smart Pump Specifications Dimensions Height: 15.5 In (39.4 cm) Width: 10 In (25.4 cm) Depth: 9 In (22.9 cm) Weight: 12 lbs (5.45 kg) Power Sources AC Input: 100 - 240 VAC 50/60 Hz universal switching power supply Automatic internal battery switchover for AC–free use or AC loss protection Facility power: 120 VAC, 10A, hospital grade receptacle AC Input Input voltage range: 100 – 240 VAC Frequency: 50/60 Hz AC fuses: 3.15A / 250V Power requirements: 1.5 A @ 120 VAC Internal DC Supply Module Output voltage: 15 VDC ± 1%, 150 mV pk-pk ripple Output current: 4A maximum Output power: 60 W maximum Overload protection: Short circuit, 110% - 150% auto recovery Over voltage protection: 115% - 130% of rated output voltage Internal Battery Type: Nickel metal hydride (NiMH) Nominal voltage: 12 VDC Rated capacity: 2.6 Ahr Over current protection: Integral PTC fuse Over temperature sense: Integral thermistor Charge time: 1 hour (80% charge), 6 hours (full charge) Power conservation: 30 days (fully charged, then unplugged) Display Type: High resolution backlit custom LCD Timer: Elapsed time numeric Pressure: Real-time digital numeric with graphic pressure gauge Air Pump Nominal power: 12 VDC, 1.25 A Flow: 10 LPM open flow Pressure Transducers Operating pressure: 0 – 15 psi Maximum pressure: 30 psi Repeatability: ± 0.2% FS typical Cuff Pressure Accuracy: ± 2% or 4 mmHg, whichever is greater, set pressure value Range: 100 to 475 mmHg Cuff Timer Range: 1 to 240 minutes Adjustment: 1 to 15 minutes – 1 minute increments; 15 to 240 minutes – 5 minute increments
