Steris HarmonyAIR G-Series Features The G-Series uses a single-color, phosphor coated LED chip for crisp, white light without the colorfringing or color-shifting effects of multi-color LEDs. This provides natural color rendition, allowing surgeons to accurately and consistently assess and interpret tissue and vessel appearance, helping provide the best possible patient outcomes. Surgical lights Single-color Phosphor coated LED 160,000 lux max central illuminance 4400K +/- 300°K Up to 96 CRI (color rendering index) Up to 98 R9 (deep saturated red color index) 50,000 hour life Steris HarmonyAIR G-Series Specifications Dimensions Diameter: 585 mm Depth of Field: 38” (97 cm) at 20%; 21” (53 cm) at 60% Pattern Size: (D10) 7” - 11” (18-28 cm); 7” (18cm) fixed General Number of LED's: 60 Maximum Central Illuminance: < 500 W/m1 Heat to Light Ratio x 3.1 mW/m2-lx D50/D10 (small pattern): 62% CCT (Color Temp): 4400 +/- 300 K CRI: up to 96 R9: up to 98 Chromaticity Coordinates: (0.369, 0.371) UV emission (300-400 nm): 2.69 W/m2 Power Consumption (LEDs only): 40 watts Life (B50, L70 definition): 50,000 hrs
