Details

More Skytron Elite 3500 Pictures Skytron 3500 Elite - Soma Technology, Inc.Skytron 3500 Hand Control - Soma Technology, Inc.Skytron 3500 - Soma Technology, Inc. Skytron Elite 3500 Features The Skytron Elite 3500 is an electro-hydraulically operated general purpose surgical table. The electro-hydraulic positioning functions (operated by the hand-held, push button, pendant control unit) are; trendelenburg, lateral tilt, back section, elevation, leg section, top slide, flex / reflex, kidney lift, return to level, and the floor lock / brake system. Manual controls are provided for head section positioning, emergency brake release, and leg section removal. Automatic Shut-Off. 500 lbs patient lift capacity. 26″ - 45″ min / max elevation. Electro-hydraulically operated. Easy-to-Use pendant / hand control. Allows full-body imaging. Skytron Elite 3500 Specifications Dimensions Height (Adjustable): 26 - 45 In (66 - 114.3 cm) Width: 21.8 In (55.2 cm) Length: 79 In (200.7 cm) Weight (Including internal battery): 12.8 lbs (5.8 kg) Power Power Requirements: 120 VAC, 60Hz, 450 Watts Current Leakage: Less than 100 micro amps Power Cord: 15 feet with hospital grade connector Motions Trendelenburg: 25° Reverse Trendelenburg: 20° Lateral Tilt (Right and Left): 20° Back (Up): 90° Back (Down): 40° Kidney Lift: 5.5″ (14 cm) Elevation Table-Up: 45″ (114.3 cm) Table-Down: 26″ (66 cm) Top Slide To Head: 7.5″ (19.1 cm) To Foot: 13.5″ (34.3 cm) Leg (up): 2° Leg (Down): 98° Head Section (Manual Positioning Up): 60° Head Section (Manual Positioning Down): 90° Battery (Optional) Type: Lead Acid Run Time: ~ 2 Weeks (Under normal operating conditions) Lifespan: ~ 4 Years
