More Skytron 3501C EZ Slide Pictures 3501C EZ Slide - Soma Technology, Inc.Skytron 3501C EZ Slide - Soma Technology, Inc.Skytron 3501C Hand Control - Soma Technology, Inc. Skytron 3501C EZ Slide Features Skytron 3501C EZ Slide surgical table is designed to meet O.R. Suite demands of the 21st Century, including an impressive range of full body imaging and articulating table functions as required for C-Arm imaging, without multiple accessories or having to reposition the patient. One touch of a button does it all! 700 lb. lift, 600 lb. articulate capacity 21” top slide Simple One-Touch Operation Removable leg section Perfect for Vascular, Neuro, Ortho and Urology Return-to-level Full articulation capacity Full body imaging without the need for special accessories Durable back-lit pendant control Battery power Skytron 3501C EZ Slide Specifications Dimensions Length w /o head rest: 69 in. (1750mm) Length with head rest: 82 in. (2080mm) Width (back / seat plate): 19.75 in. (500mm) Width with side rails (back / seat plate): 21.75 in. (550mm) Weight: 827 lbs. (376kg) Permissible Load: 700 lbs. (320kg) Lift / 600 lbs. (275kg) Articulation Adjustments Via Hand Control Height: 26-45 in. 660-1140mm Lateral tilt (left/right): 20° Trendelenburg: 25° Reverse Trendelenburg: 20° Power Kidney Bridge: 6 in. Lift 150mm Lift Back up/down: 90°/40° Leg up/down: 2°/98° Return to level (anatomically correct return to horizontal position from articulated positions) Top slide/head: 7.5 in. 195mm Top slide/foot: 13.5 in. 335mm Flex/Reflex: 40°/90°
