Details

More Skytron 3003 Impulse Pictures 3003 Impulse Imaging Table - Soma Technology, Inc.3003 Impulse - Soma Technology, Inc.Skytron 3003 Impulse Joystick - Soma Technology, Inc. Skytron 3003 Impulse Features The 3003 Impulse puts automatic control of the imaging surface right at your fingertips. Featuring joystick control, the table offers 65” of unobstructed imaging. The two-speed, multidirectional top slide takes the work out of manual maneuvers and automatically manipulates the imaging surface. 20” longitudinal and 8” lateral top slide 500 lb lift and articulation weight capacity Two-speed, multidirectional joystick control 28”- 42” adjustable table height 83” carbon fiber top 65” unobstructed imaging window 20° lateral tilt 20° Trendelenburg and reverse Trendelenburg Skytron 3003 Impulse Specifications Dimensions Length: 83” (2,100 mm) Width: 19 5/8” (500 mm) Width (With Side Rails): 22” (560 mm) Adjustments Via Hand Control Height: 28”-42” 710-1065 mm Lateral tilt (left/right): 20° Trendelenburg: 20° Reverse Trendelenburg: 20° Joystick Control For operation, top button on joystick control must be depressed Orientation Button: Reverse Normal Center Button: Moves table top to center position Speed: High Low Max Permissible Load 500 lb (227kg) Lift 500 lb (227kg) Articulation
