Schiller At 10 Plus Features The Schiller Welch Allyn AT-10 Plus ECG is a Resting ECG complete with Interpretation and Memory, Laptop design, built-in 8.5”x11” printer, built-in LAN and VGA Output ports. The AT-10 plus is made by SCHILLER, a world-leading manufacturer of cardiopulmonary diagnostic systems. Combining high quality and easy operation, the unit can be used wherever ECG and spirometry data must meet highest demands. There is a reason why its famous predecessor, the CARDIOVIT AT-10, is used in many clinics and practices and even in the international space station ISS and its control centres. NATO armies also place their trust in SCHILLER‘s quality. They use more than 20,000 units world-wide. Laptop / Tilt-screen Design High Resolution 10.4" TFT Color LCD screen 12-Channel Resting and Exercise ECG 15VAC and battery operated Easy Operation of all ECG functions Built-in thermal printer with 8.5"x11" z-fold printing paper Built-in RS-232 interface for data transfer to SEMA 200 (with Serial cable) Built-in LAN interface for data transfer via XML Bi-Directional Communications Options, including: LAN, Wireless (Wi-Fi), and/or Modem Optional barcode scanner for EMR Records Schiller At 10 Plus Specifications Spirometry Measured Values Slow spirometry: SVCin, SVCex, SVCmax, ERV, IC, IRV ... Forced Spirometry: FVC, FEV1, FEV6, FEV1/FVC, FEV1/FEV6, FEF25-75%, PEF, MEF75%, MEF50%, MEF25%, FEF25%, FEF50%, FEF75%, FEF0.2-1.2, FMFT, FIVC, PIF ... MVV: MVV, RR, TV Presentation Flow/volume loop Flow/loop curve Volume/time curve Measurements table Interpretation programs Predicted Values (Standard Values) Adults: ECCS, Forche97, Berglund, Finnland, Indien, Hankinson (NHANES III), Knudson/ITS, Knudson76/ITS, Crapo 1981, Morris/ITS, Composite, Polgar Paediatric: Quanjer & Tammeling, Forche97, Indien, Knudson / ITS, Knudson76/ITS, Polgar, Hankinson (NHANES III) Comparison pre/post medication possible Extrapolated predicted values Standards: ATS, ERS Dimensions 118 x 36 x 28 mm, approx. 120 g Measuring Method Pneumotach sensor Measuring Range Flow: 0 to +/- 14 l/s Volume: 0 to +/- 11 l Measurement Accuracy In accordance with ATS/ERS Flow Impedance < 0.2 mbar * s/l at 12 l/s
