Schaerer Arcus 601 Features The schaerer® arcus is the latest innovation from SCHAERER MEDICAL USA, INC. Featuring the famous Schaerer offset cantilevered base for maximum imaging access, the arcus is designed for general surgery as well as specialty use. The arcus is extremely easy to use and can support patient weights up to 800 lbs in both normal and reverse orientation. Like all of our products, patient safety and operating convenience are of primary importance. 4 Large double wheels 5th wheel for better mobility Floor locks, electro-hydraulic, self leveling Base cover, directing liquid to the floor, easy to clean Designed for foot space and C-arm access 800 Lb weight capacity throughout the entire range of motion Schaerer Arcus 601 Specifications General Weight without head and leg plates: 688lbs Length without head and leg plates: 44.5 inches Length with head and leg plates: 83.5 inches Width of table top: 20.5 inches Total width (with side rails): 22.5 inches Width with lateral table extension: 34.6 inches Maximum patient weight: 800 lbs Height adjustment with patient weight up to 577 lbs (top edge pad, blocked table): 23.4 - 47.2 inches Height adjustment with patient weight over 577lbs (top edge pad, blocked table): 23.4 - 47.2 inches Trendelenburg / reverse Trendelenburg: 30° Lateral tilting right/left: 20° Seat plate up: 65° Seat plate down: 40° Motorised leg plate up: 80° Motorised leg plate down: 110°
