Philips Respironics Trilogy 202 Features The Trilogy 202 is both a volume-control and pressure-control ventilator for invasive and noninvasive ventilation. The versatile breath delivery and setup options free you from burdensome equipment exchanges, providing greater continuity of care for your patients. Because the Trilogy 202 has the unique ability to compensate for leaks in both pressure and volume control modes, using simpler passive circuits may support significant time and cost savings. With one simple setting change, the Trilogy 202 supports either active or passive exhalation breathing circuits to accommodate changes in circuit preference. Compact design with long-life internal battery for intra-hospital transport. Supports active and passive circuits for invasive and noninvasive ventilation. Innovative leak compensated volume control ventilation. Philips Respironics Trilogy 202 Specifications Controls CPAP : 4 - 20 cmH20 (passive leak port circuits) cm H2O IPAP: 50 cm H2O EPAP/PEEP (a) : 0 - 25 cmH20 (active valve circuits) cm H2O EPAP/PEEP (b): 4 - 25 cmH20 (passive leak port circuits) cm H2O Pressure support: 0 – 30 cmH2O cm H2O Tidal volume: 50 - 2000 ml Breath rate(a): 0 - 60 BPM (AC mode) beats per minute Breath rate(b): 1 - 60 BPM (all other modes) beats per minute Inspiratory time: 0.3 - 5.0 s Synchrony features Rise time: 1 - 6 (relative scale) Ramp start pressure (a): 0 - 25 cmH20 (active circuits) cm H2O Ramp start pressure (b): 4 - 25 cmH20 (passive circuits) cm H2O Ramp start pressure (c): 4 - 19 cmH20 (CPAP mode) cm H2O Ramp time Off: 5 - 45 min C-Flex Off: 1 - 3 (relative scale) Flow trigger sensitivity: 1 - 9 l/min Flow cycle sensitivity: 10 - 90 % Environmental Operating temperature: 5 – 40 °C Relative humidity: 15 - 95 % Storage temperature: -20 – 60 °C Atmospheric pressure: 60 - 110 kPa (450 - 825 mmHg) Electrical Input voltage: 100 - 240 VAC and 50/60 Hz and 2.1 A Detachable battery voltage: 14.4 VDC Internal battery life: 3 hours under normal conditions hr Detachable battery life: 3 hours under normal conditions hr external battery connection: 12 VDC Volume Modes MPV Mouthpiece Ventilation Mode: Yes Pressure control (PC): Yes Synchronized intermittent mandatory ventilation (SIMV): Yes SIMV with pressure support (SIMV w/PS): Yes Control ventilation (CV): Yes Alarms Low tidal volume Off: 50 - 2000 ml Circuit disconnect Off: 10 - 60 sec Apnea Off: 10 - 60 s and 4 - 60 BPM High tidal volume Off: 50 - 2000 ml High minute ventilation Off: 1 - 99 l/min Off, 1 - 99 l/min Low minute ventilation Off: 1 - 99 l/min High respiratory rate Off: 4 - 80 beats per minute Low respiratory rate Off : 4 - 80 beats per minute Pressure Modes Pressure control (PC): Yes Pressure control-SIMV (PC-SIMV): Yes Spontaneous ventilation (S): Yes Spontaneous ventilation with timed back-up (S/T): Yes Timed ventilation (T): Yes Options Detachable back-up battery: Offering up to 3 hours additional operating time Hospital roll stand: Provides convenient accessory basket and humidifier mount DirectView: 1 GB SD card data storage integrated into the ventilator software Monitored Parameters Tidal volume: 0 - 2000 ml Minute ventilation: 0 - 99 l/min Estimated leak rate: 0 - 200 l/min Respiratory rate: 0 - 80 beats per minute Peak inspiratory flow: 0 - 200 l/min Peak inspiratory pressure: 0 - 99 cm H2O Mean airway pressure: 0 - 99 cm H2O % patient triggered breaths: 0 - 100 % I:E ratio: 9.9:1 - 1:9.9 Synchrony Features Auto-Trak sensitivity: Auto-Trak sensitivity Auto-adaptive triggering, cycling, and leak compensation (available in all modes, passive circuit only) Adjustable flow triggering: 1 – 9 l/min (available in all modes and circuit types) l/min Circuit Types Active exhalation valve with proximal airway pressure (PAP): Yes Active exhalation valve with flow sensor: Yes Passive exhalation port: Yes
