Philips IntelliVue MP2 Features The Philips IntelliVue MP2 portable patient monitor is compact in size, ergonomic, and modular in design. It provides an easy-to-use touchscreen user interface, is highly customizable and shares a technological platform with the Philips IntelliVue MP5-MP90 patient monitors. The IntelliVue series offers a complete monitoring solution that is flexible and modular, designed to suit a broad spectrum of monitoring needs. Compact, rugged, lightweight monitor with built-in measurements. ECG monitoring using any combination of three to 10 electrodes. 12-lead ECG monitoring with five electrodes using the EASI method or with 10 electrodes using the conventional method. Multi-lead arrhythmia and ST segment analysis at the bedside on all available leads. Philips IntelliVue MP2 Specifications Dimensions Height: 3.9 In (9.9 cm) Width: 7.4 In (18.8 cm) Depth: 3.4 In (8.6 cm) Weight: 2.8 lbs. (1.3 kg) Power Power Consumption: <40 W average, <65 W peak Line Voltage: 100 to 240 V ~ Current: 1.3 to 0.7 A Frequency: 50/60 Hz Display Touchscreen and hard keys as input device 3.5” TFT flat panel display with QVGA (320 x 240) resolution, wide viewing angle, large numerics Cardiotach Range Adult / Pedi: 15 to 300 bpm Neo range: 15 to 350 bpm Accuracy: ±1% of range Resolution: 1 bpm Sensitivity: ≥200 μVpeak PVC Rate Range: 0 to 300 bpm Resolution: 1 bpm ST Numeric Range: -20 to +20 mm Accuracy: ±0.5 mm or 15%, whichever is greater Resolution: 0.1 mm QT Numeric Range: 200 to 800 ms Accuracy: ±30 ms Resolution: 8 ms QTc Numeric Range: 200 to 800 ms Resolution: 1 ms ΔQTc Numeric Range: -600 to +600 ms Resolution: 1 ms QT-HR Numeric Range (adult): 15 to 300 bpm Range (Pediatric and Neonatal): 15 to 350 bpm Sinus and SV Rhythm Ranges Brady Adult: 15 to 60 bpm Pedi: 15 to 80 bpm Neo: 15 to 90 bpm Normal Adult: 60 to 100 bpm Pedi: 80 to 160 bpm Neo: 90 to 180 bpm Tachy Adult: >100 bpm Pedi: >160 bpm Neo: >180 bpm
