Mindray A7 Features Mindray A-Series Anesthesia Delivery Systems help you manage complex challenges with an intuitive, easy to use, safe and reliable approach to anesthesia delivery. The new A7 Anesthesia Workstation takes the popular A-Series to a higher level. The feature-rich A7 combines traditional bellows driven ventilation with electronic fresh gas technology providing effective care across a wide range of patients. Electronic gas flow with easily customizable settings and direct flow or total flow options Quick keys for changing O2 flow Low flow optimizer provides visual indication of efficient fresh gas flow setting, supporting the patient while reducing cost and waste gas Agent usage calculation feature displays amount of agent used with each case Automatic system compliance and fresh gas compensation 15” color LCD touchscreen with control pad HL7 connectivity for AIMS and EMR data export Mindray A7 Specifications Pneumatic Specifications Pipeline Gas Supply Requirements Pipeline Input Range: O2, N2O, Air 280 – 600 kPa (40 psi – 87 psi) Pipeline Gas Supply Connectors DISS threaded body as per CGA V-5 Cylinder Gas Supply Requirements Compatibility E-Cylinder (O2, N2O, Air) Cylinder Gas Supply Connectors Pin indexed (PISS) per CGA V-1 Electrical Specifications Power and Battery Back-up Mains Power Supply: 100 – 120 VAC 50/60 Hz Current Input: 12A total max Power Consumption: Approx. 200 VA Power Cord: Hospital grade line cord 5 m (16 ft) Backup Battery Power Run Time Approx. 90 minutes Charge Time 8 hours max Auxiliary Outlets Number and Type of Outlets Four circuit breaker (3A each) Environmental Specifications Operating Temperature: +10 – +40°C (50 – 104°F) Storage Temperature: -20 – +60°C (-4 – 140°F) Humidity: 15 – 90% RH, non-condensing (operating and storage) Dimensions Height: 140 cm (55.1 in) Width: 105 cm (41.3 in) Depth: 80.5 cm (31.7 in) Weight: (without vaporizers and gas cylinders) 185 kg (408 lbs)
