Details

Midmark Ritter M9 Features The M9 autoclave couldn’t be easier and is time tested for reliability. You simply load it...set it...and forget it. Select your cycle and the time is set for you. Press “Start” and the M9 fills with the correct amount of water. Once the sterilization process is complete, the door opens automatically and quietly to dissipate the steam, giving you fast drying time for your instruments. Exclusive automatic-opening door for ease of use and a quick drying time Steam–Flush Pressure Pulse Air Removal System ensures proper steam penetration Self Program Controls enable you to create different cycle parameters to meet specific instrument processing needs Pre-Programmed Controls for convenience LCD Display for easy view of indicators Midmark Ritter M9 Specifications Dimensions Overall length w/plug: 20.4” (51.8 cm) Overall width: 15.3” (38.9 cm) Overall height w/printer: 15.8” (40.1 cm) Minimum Countertop area: 15.3” x 17.9” (38.9 cm x 45.4 cm) Chamber 9” diameter (22.9 cm) 15” depth (38.1 cm) 3.5 gal. usable volume (13.4 liters) Trays Two large –7.3”W x 12” L x .8” D (18.6 cm x 30.5 cm x 2.2 cm) Two small– 5.6” W x 12” L x .8” D (14.3 cm x 30.5 cm x 2.2 cm) Weight Unit weight: 73 lbs. (33.1 kg) Shipping weight: 81 lbs. (36.7 kg) Water reservoir capacity: 1.1 gal. (4.1 liters) Electrical Requirements 115 VAC, 50/60 Hz, 15 Amps Single Phase 115 VAC has 1425 watt tubular immersion heater Safety Standards UL61010-1, UL61010-2-040 CAN/CSA C22.2 No. 61010-1 CSA C22.2 No. 61010-2-040-07 Part 2-040
