Hologic Fluoroscan Insight 2 Features: The Hologic Fluoroscan Insight 2 mini C-Arm C-Ray System is designed to meet all extremity imaging needs. Designed with its exclusive rotating capabilities, the Insight 2 is extremely dependable providing imaging versatility right in the surgical suite. The Fluoroscan Insight 2 has tremendous maneuverability and delivers an ultra-fine low dose fluoroscopy to produce high-resolution images. This mini C-Arm features a lightweight, flat screen monitor that can be rotated and positioned with ease. Outstanding precision and versatility in extremity surgery. Combines tremendous maneuverability, ultra-fine fluoroscopy images,and automated adjustments that deliver optimum images. Lightweight, flat screen monitor can be rotated and positioned with effortless ease. Hologic Fluoroscan Insight 2 Specification: X-Ray Source Focal Spot Size: 0.045 mm Tube kVp Range: 40 to 75 kVp Tube Current Range: 0.020 to 0.100 mA Image Intensifier Dual Mode 4" (10cm) and 6" (15cm) Monitor 20" LCD Flat Panel Touch Screen Sensitivity Resolution: 1200 x 1600 HD Quality Display Image Matrix Size 1k x 1k High Definition X-ray Power Control Auto and Manual Mode C-Arm Free Space: 14" (36 cm) Depth: 16" (40.6 cm) Orbital Rotation: 120° Horizontal Travel: 23° Vertical Travel: 23" (58 cm) Pivot Rotation: 380° Panning Motion: 320° Image Storage Permanent Hard Drive: 7,000 images Removable Data Storage: USB port, CD/DVD-RAM drive Image Acquisition Rate of 30 fps (standard imaging) Rate of 25 fps (cine (digital) recording) Imaging Features Snapshot Continuous Cine (Digital) Recording Imaging Features Brightness/Contrast Control Automated Image Processing Real-Time Noise Reduction Edge Enhancement Auto-Dose Control Magnify-Zoom-Pan Footswitch Options Triple Function Footswitch (standard) Printer Options Small Format Thermal Printer Large B/W Hybrid Graphic Printer Full DICOM Connectivity DICOM Store / send / print / modality work list Space Allocation Door size: 30" minimum Power Requirements 100, 120, 220, 240 VAC selectable 50/60 Hz input; 75 VA
