Details

GE Logiq 9 Features Logiq 9, GE's leadership ultrasound system, Introduces new exciting enhancements that will change the ultrasound impact with any clinical application, both in image quality and workflow efficiencies. The Volume Ultrasound suite enables to acquire and further navigate within Volume data set, to acquire and further navigate within Volume data set, to explore the smallest details with stunning clarity. New Volume features enable you to perform at a highest level, providing new information and re-designing the approach to patient. Adjustable 19" flat-panel monitor, that also folds down for clear visibility during transport Floating keyboard console to keep everything within arm's reach Voice-activated operation to allow the freedom to perform multiple tasks simultaneously Color touch screen and programmable keys for one-touch efficiency GE Logiq 9 Specifications Dimensions Size: (H x W x D) 55.3"-63.3" (140.3-160.7 cm) x 25.2" (64cm) x 35.4" (89.9 cm) Weight: 434 lbs Operator Keyboard Floating keyboard adjustable in three dimensions: Height: adjustable 76.2 - 96.5 cm( 30- 38 in) Rotation: Adjustable +/- 75o from center Extension: 31,8 cm (12.5in) from Console Full-sized, backlit alphanumeric keyboard Ergonomic hard key layout interactive back-lighting Integrated recoding keys for remote control of up to 4 peripheral or DICOM devices Integrated gel warmer Touch Screen 10.4 in High Resolution color LCD screen Interactive dynamic software menu Brightness adjustment User-configurable layout Monitor 17" high resolution non-interlaced scan flat CRT Center of monitor height adjustable (with keyboard): 125.7 146.1 cm (49.5 - 57.5in) Tilt/Rotate Adjustable Monitor Tilt Angle: Down 10°, Up 10° Rotate Angle: 90° right, 90° left Wide image area Integrated high-fide;it speakers Digital brightness & contrast adjustment Console Design 4 active Probe Ports Integrated HDD (40 GB) Integrated CD-RW drive Integrated MO drive On-board storage for peripherals Integrated cable management Front and rear handles Easily removable air filter
