Dräger Fabius GS Premium Features: High-contrast color monitor with the Dräger user interface for easy and familiar operation. All major ventilation modes. New, highly maneuverable trolley with central brake. Integrated LED workplace illumination. Solid, spacious design with large drawers. Industry standard rails for additional Dräger and third party equipment. CLIC absorber compatibility prevents contact with soda lime. Dräger Fabius GS Premium Specifications: Weight: (Base unit without vaporizers or cylinders): 296 lbs (134.2 kg) Dimensions: (W) 30 in × (H) 52 in × (D) 33 in) Power Supply: 100-240 VAC, 50/60 Hz, 2.3 A max. Battery (supports ventilator and monitor): > 45 min. Ventilator E-Vent: Electronically controlled, electrically driven. Breathing Frequency: 4 to 60 bpm. Max. Minute Volume (MV): 99 L/min. Positive End-Expiratory Pressure (PEEP): 0-20 cmH2O. Inspiration / Expiration Ratio (Ti:Te): 4:1 to 1:4. Pressure Limiting (Pmax): 15-70 cmH2O. Tidal Volume (Vt): 20-1400 mL in Volume Control. 20-1100 mL in SIMV/PS. Inspiratory Pause (Tip:Ti): 0 - 50 %. SIMV Inspiratory Time (Tinsp): 0.3 - 4.0 sec. Inspiratory Pressure (Pinsp): PEEP + 5 to 65 cmH2O. Inspiratory Flow (InspFlow): 10-75 L/min in Volume and Pressure Control. 10-85 L/min in Pressure Support. Pressure Support Level (ΔPPS): PEEP + 3 to 20 cmH2O. Min. Freq. for Apnea-Ventilation (Freq. Min.): 3-20 bpm and "OFF". Trigger: 2-15 L/min. Range of Fresh Gas Flow Indicators: 0.00 to 12.0 L/min. Total Fresh Gas Flow Meter: 0 to 10 L/min. Calibrated with a mixture of 50 % O2 and 50 % N2O mixture. O2 Flush: 87 psi (6 bar): max.75 L/min 41 psi (2.8 bar): min 25 L/min
