Dräger Apollo Features Apollo® optimizes the anesthesia workflow and reduces process costs with features such as the fully automatic self-test. Since no user interaction is required, users are free to get on with other jobs. In addition to providing invaluable assistance through best-in-class therapy, Apollo® also offers an open-platform architecture - enabling it to be easily integrated into the overall workflow. User-friendly ergonomics. All functional elements are within easy reach of being seated or standing. Unique breathing bag arm design provides the ultimate flexibility. Simple straightforward startup makes it easier for the staff and provides complete information on device status. Integrated breathing system eliminates external hoses and clutter, reducing risk of misconnection and disconnection. Fully automatic self-test lasts approximately three minutes, reflects the results to the user, and makes results available at any time. Advanced ventilation. E-Vent plus servo controlled high-speed piston ventilator works with great precision to supply a maximum peak flow far in excess of any bellows ventilator, resulting in the kind of performance previously only seen in the ICU. The consistent use of low-flow anesthesia techniques can significantly reduce the cost of inhalational anesthetic agents. Reducing the fresh gas flow from 3L/min to 1L/min can result in anesthetic agent savings of up to 50%. Dräger Apollo Specifications Weight (Without vaporizers and gas cylinders) 365 lbs. (165 kg) Dimensions (H x W x D) 59 x 33.5 x 31.5 inches (150 x 85 x 80 cm) Power 200 W, typically. Operating voltage 100 to 127 VAC (- 15 % + 10 %) 45 - 65 Hz. Integrated Power Backup At least 30 min, typically 90 min; Depending on ventilation parameters. Ventilator E-Vent® Plus Electrically driven and electronically controlled, fresh gas decoupled. Ventilation modes Manual, spontaneous, Volume Mode, Pressure Mode Optional/Synchronization: Pressure Support (PS), Volume Mode Autoflow. Pressure limitation PMAX (in Volume Mode) (PEEP + 10) up to 70 cmH2O. Pressure limitation PINSP (in Pressure Mode) (PEEP + 5) up to 70 cmH2O. Trigger 0.3 - 15 L/min. Tidal volume VT (compliance compensated) (in Volume Mode) 20 - 1400 mL 10 - 1400 mL with option Pressure Support. Breathing frequency (freq.) 3 - 100 bpm. Inspiration time (TINSP) 0.2 - 6.7s Inspiration/Expiration time ratio (I:E) max. 5:1 Plateau time (TIP:TINSP) 0 - 60 % Inspiratory flow (in Pressure Mode) max. 150 L/min PEEP in Volume Mode 0 - 20 cmH2O (max. PMAX - 10 cmH2O) PEEP in Pressure Mode 0 - 20 cmH2O (max. Pinsp - 5 cmH2O) *Autoflow Mode *Optional Fresh-gas flow 0 - 10 L/min for each gas. (oxygen, air, nitrousoxide.) TSLOPE (in Pressure Mode and Pressure Support.) 0 - 2 s Total system leakage < 150 mL at 30 cmH2O. (automatic leak test.) O2 flow control Sensitive ORC function: at least 21 Vol.% with N2O as carrier gas. O2 flush > 35 L/min.
