Details

BIO-MED Devices Crossvent 3+ Features You can order the Crossvent 3+ in any one of three configurations: Standard, with Bio-Med Devices Air/Oxygen Blender attached or with air entrainment. The attached blender allows the user to set oxygen concentration from 21% to 100%. Units with air entrainment can deliver either 100% oxygen or a nominal 50% oxygen without the need for an external air supply source. The unique venturi mechanism built into the unit increases oxygen tank life by mixing ambient air with the source oxygen. Ultra-compact and lightweight design Unmatched gas efficiency Long battery life Multiple Ventilation modes Built-in PEEP LED power indicator Foolproof circuit connections BIO-MED Devices Crossvent 3+ Specifications General Parameter Range Rate 5-150 bpm Tidal Volume 5-2500 ml Inspiratory Time 0.10 – 3.0 seconds I/E Ratio 3:1 to 1:99 Flow Rate 1-120 lpm Peak Pressure 0-120 cmH2O PEEP Pressure 0-35 cmH2O Pressure Trigger -.2 to –10 cmH2O Pressure Support 0-50 cmH2O SIMV Rate 0.6-50 bpm O2 Sensor 21-100% Sigh 0-2500 ml Ventilation Modes Assist Control | SIMV CPAP | Pressure Support | Sigh
