Biodex 840 Surgical Table Features The Biodex 840 Surgical C-Arm Table has an extra-large, 71” radiolucent area, free-float X-Y tabletop, motorized control of height, isocentric lateral roll, Trendelenburg motions and the catheter tray extension make the Surgical C-Arm Table - 840 ideal for cardiovascular procedures. The radiolucent area is free of cross members, allowing full fluoroscopic visualization and unobstructed C-Arm positioning. Free-float tabletop with specially-designed SmoothGlide movement. Expansive head-to-toe tabletop motion, 35”. Extra-large radiolucent area, 71”. High-speed actuators assure quick tabletop positioning, height adjustability, isocentric lateral roll and Trendelenburg motions. Isocentric lateral roll maintains image center during tabletop movement, minimizing image distortion. Biodex 840 Surgical Table Specifications Dimensions Height (Adjustable): 33 - 43 In (84 - 109 cm)/li> Width: 26 In (66 cm)/li> Length: 100 In (254 cm)/li> Weight: 641 lbs Tabletop Length: 97 In (246 cm) Width: 24 In (61 cm) Material: Carbon fiber Mattress: Seamless, 2 In (5cm) thick Motions Height Adjustable: 33 - 43 In (84 to 109 cm) Tabletop X Motion (head-to-toe float): 35 In (88.9 cm) Tabletop Y Motion (side-to-side float): 10 In (25.4 cm) Trendelenburg: 0° to 20° Reverse Trendelenburg: 0° to 20° Lateral Roll: 0° to ±15° Controls Hand Control: Height, lateral roll and Trendelenburg motions Foot Control: Activates all motions (has release for float) Mushroom-Top Control: releases X-Y Tabletop motions General Wheels Head End: 3” (7.62 cm) swivel casters, integral locking system on base Foot End: 5” (12.7 cm) swivel casters with central locking Accessory Rails: Standard OR accessory rails 49.5 x 1.12 x .375 In (124 x 2.86 x .95 cm) mounted near foot end of table Patient Restraints: Three body straps Finish: Stainless Steel Patient Capacity: 500 lb (227 kg); weight tested to four times the patient load rating. Lift Capacity: May vary between 460 lb - 500 lb (209 - 227 kg) based on line voltage Power: 115 VAC or 230 VAC and battery
