Axia V1050T Touch ScreenFeatures The Axia V1050T monitor is an intuitive touch screen patient monitor; patient information along with vital sign settings can be quickly modified to meet the needs of a patient s changing condition. Its upgradable design fits-in and moves amongst many patient care areas. Offers ECG with arrhythmia detection, standard measurements of: non-invasive blood pressure, motion tolerant SpO2, temperature and respiration rate. The Axia V1050T monitor offers several connective solutions to network multiple monitors and/or manage patient data on an electronic medical records platform or a based hospital information system. High resolution 10.5 inch touch-screen display Auto setting of alarm limits Color-coded alarms Graphical and tabular trends (72 hours) Patient data entry Battery backup (removable batteries) Networking capability (wireless and non-wireless) • Color of the waveforms can be changed Applications: Neonatal, pediatric and adult patients Axia V1050T Touch Screen Specifications Display 10.5 inch color touch screen Trace 8 waveforms Indicator Alarm indicator Power indicator QRS beep and alarm sound Trend Time 1 - 72 hour Recorder: Built-in, thermal array, 3 channels Record width: 48mm Recorder paper: 50mm Record speed: 25mm/s, 50mm/s Networking Industry standard 802.11b/g wireless network Power Source: External AC power or internal battery AC Power: 100 ~ 240VAC, 50/60Hz, 150VA Battery: Built-in & rechargeable lithium ion Operating Time: 3+ hours Environmental Specifications Input: 5-lead ECG cable and standard AAMI line for connection Lead Choice: I, II, III, aVR, aVF, aVL, V, V1-V6, TEST Gain Choice : x0.5, x1, x2, x4 Frequency Characteristic: 0.05 ~ 35 HZ (+3dB) ECG Waveforms: 7 channels Penetration Voltage: 4000VAC 50/60Hz Sweep Speed: 12.5, 25, 50 and 100 mm/sec (left to right or right to left) HR Display Range: 30 ~ 300bpm Accuracy: ±1bpm or ±1%, whichever is greater Alarm Limit Range Setting: upper limit 100 ~ 200bpm, lower limit 30 ~ 100bpm RESP Measure Method: RA-LL impedance Range: 0 ~ 120 rpm Accuracy: ±3 rpm Alarm Limit Setting: upper limit 6 ~ 120 rpm, lower limit 3 ~ 120 rpm Sweep Speed: 12.5, 25, 50 and 100 mm/sec (left to right or right to left) Sp02 ASpO2: Anti-motion SpO2 SpO2% Range: • SpO2 Accuracy: 0-100% Pulse Rate Range: ±2% (70 ~ 100%, non-motion), ±3% (70 ~ 100%, motion) Pulse Rate Accuracy: ±2 bpm (non-motion, ±3 bpm (motion) Alarm Limit Setting: upper limit 70 ~ 100%, lower limit 70 ~ 100% SpO2 Probe: Red light LED wavelength 660nm±5nm, Infrared light LED wavelength 940nm±10nm
