Details

Clasifications: Regulatory: Class I according to 93/42 EEC Medical Device Directive for EEA Electro-Mechanical: Class i per IEC60601-1, UL2601, CSA 22-2 601-1 and JIST 0601 Console dimensions: Height: 138 cm (63 inches) Width: 51 cm (23 inches) Depth: 57 cm (30 inches) Console Weight: Unpacked: 107 kg (235 pounds) Packed: 150 kg (330 pounds) Environmental limitations: operating non-operating packaged for transport Altitude 2438 meters (8,000 feet) - - 12,191 meters (40,000 feet) Temperature 10º C to 35º C (50º F to 95º F) -10º C to 55º C (14º F to 131º F) -40º C to 70º C (-40º F to 158º F) Relative 10% to 95% 10% to 95% 10% to 95% Humidity without condensation without condensation without condensation Electrical requirements Auto select to accomodate input powerof 90 VAC -264 VAC, 50/60 Hz. Maximum input current is 6 Amps, and maximum power consumption does not exceed 1000 watts Power system 24VDC 650W AC to DC power supply; 12VDC 450W AC toDC power supply; AC input module; 12V lead acid battery; Power distribution PCB; Host DC to DC PCB Leakage current: 300µA @ 132 VAC,60Hz; 500µA @ 264 VAC, 50Hz Protection against electric shock: Class I Classification of all applied parts: Type BF Data card: MMC (multimedia card) or SD (secure digital) 32 minimum Touch screen and display 15" analog resistive touch screen, 15" TFT-LCD, 1024x768 pixels, +12 VDC ±5%, 3 Amps maximum. Tilt +5º to -90º, spin +45º CW to -180º CCW, swivel ±87.5º CW & CCW Ultrasound driver 34 Khz to 42 Khz, 3.5 ±0.5 mils stroke U/S Handpiece Resonant frequency 40KHz Dynamic operating frequency: 35.5 kHz to 40.5 kHz Neosonix handpiece: Resonant frequency 36 kHz to 41 kHz VIT cutter 50 to 800 cpm IV pole Travel range of 97 cm (38.19 inch), speed from 8.0 cm/s to 12.0 cm/s Remote control one way wireless transmitting device. IR transmitting diodes in the range of 880 nm to 950 nm wavelength. Requires three AAA batteries Footswitch dimensions Height: 12.7 cm (5.0 inches) Width: 24.1 cm (9.5 inches) Length: 34.9 cm (13.75 inches) Footswitch weight: Stand alone: 16.5 kg (7.5 pounds) With cable: 18.7 kg (8.5 pounds)
