Schiller CARDIOVIT AT-2plus 12-Channel Resting EKG Machine w/ Spirometry
Details
The AT-2plus Combo is a low cost ECG & Spirometry system with performance features previously only available in high priced systems. The AT-2plus provides A4 reports within seconds - at the touch of a button. All the features of the popular AT-2, PLUS a large, high resolution backlit monitor for easy preview of ECG quality and the Spirometry test, and full alphanumeric keyboard. Features and Benefits 6/12 channel representation of all 12 simultaneously acquired leads Large, high resolution backlit monitor for easy preview of ECG quality Pulmonary Function Testing for FVC, SVC, MV and MVV The unique SP-250 disposable sensor minimizes the risk of cross-contamination Automatic and manual mode Full size 8 1/2" x 11" reports (A4) Integrated rechargeable battery lasts up to 3 hours of normal use Single button operation SCHILLER filter technology Computerised ECG interpretation program including accurate measurements (optional) RS-232 interface for data transmission to PC SEMA-200 Meets or exceeds U.S. and international quality standards Portable at only 4.8 kg / 11 lbs
Additional Information
Materials Included AT-2 Plus ECG Unit 3L Calibration Syringe SP250 Spirometry Sensor 10 Disposable Mouthpieces 2 Nose Clips 10 Lead Patient Cable 10 Snap Clip Electrode Adapters 500 Disposable Electrodes One (1) pack of paper Power Cable User Manual
Tech Specs
Technical Specifications Dimensions: 400 mm x 330 mm x 101 mm Weight: Ca. 2.9 kg / approx. 6.7 lbs Power supply requirements: 220 – 240 V (nominal), 50/60 Hz or 110 – 115 V (nominal), 50/60 Hz independent operation with built-in rechargeable battery, LED indicator for mains and battery, built-in charger unit Power consumption: Max. 28 VA Battery charging time: 15 hrs. from a completely discharged battery, 3 hrs. to 60 % capacity Battery capacity: 2 hrs of normal use Leads: Standard / Cabrera Patient input circuitry: Fully floating and isolated, defibrillation protected (only with original SCHILLER patient cable) Frequency range of digital recorder: 0 Hz to > 150 Hz (IEC/AHA) Myogram (muscle tremor) filter: 25 Hz (40 dB/dec) or 35 Hz (20 dB/dec), programmable Line frequency filter: distortion-free suppression of superimposed 50 or 60 Hz sinusoidal interferences by means of an adaptive digital filter Control panel: Pad keys, LED indicators
Shipping Information
Please Inquire
Warranty & Returns
3-year warranty
