Schiller 2.293000 BR-102 Plus 24-Hour ABPM
Details
SCHILLER's ABPM system provides doctors with quick and reliable results, optimizing patient therapy and treating cardiovascular diseases more efficiently. The latest software facilitates compliance with legal obligations with regard to integrity, availability, safety and data protection. The BR-102 plus is clinically validated and meets all four internationally recognized standards: British Hypertension Society (BHS) European Society of Hypertension International Protocol (ESH) Association for the Advancement of Medical Instrumentation (AAMI) SP10 Recommended by dabl® Educational Trust Features and Benefits Light and compact design. Motion-tolerant technology reduces re-inflates and failed readings. Dynamic inflation to 30 mmHg above the previous systolic measurement reduces measurement time. Built-in pump, and thus almost silent SD card memory eliminates the risk of lost data and re-tests. Five cuff sizes, from the pediatric to the XL adult size, guarantee optimal measurement accuracy and maximum comfort DARWIN ABPM is a user-friendly, Windows®-based program that allows maximum flexibility for configuration, analysis, interpretation and ABPM reporting. Comprehensive and professional reports can be generated in no time. Performs with Oscillometric Measurement Method. Materials Included BR-102 Plus Unit (1) Medium Size Blood Pressure Cuff (1) Tubing (1) Carrying Pouch (1) Patient Belt (1) Shoulder Strap (1) Carrying Case (4) AA Batteries (1) Battery Charger (1) USB Interface Cable (1) Darwin Software (1) User Manual
Tech Specs
Dimensions: 4" x 3" x 1" Weight: 0.44 lbs Power: 2 rechargeable NiMH batteries (≥ 2700 mAh), type “AA”1 Display: Color LED display with multi-language menu Interface: USB interface for data transfer Programming: Menu guidance; 2 buttons Validations: ANSI /AAMI SP10 Measurement Duration: 24 hours or 48 hours BP Range: 25 - 300 mmHg HR Range: 40 - 300 bpm Deflation Speed: 2 - 9 mmHg/s or automatic Monitoring Protocols: 4 modifiable interval groups (each group has 8 measurements) Measurement Intervals: 5 - 120 min Event Key: Program to allow additional patient readings Data Storage: Flash memory stores and 30 s of voice recording Additionally Storage: microSD card PC Requirements: USB port Ambient Conditions: Temperature Operation: 10 ° to 40 °C Transport/storage: -10 ° to 50 °C Humidity: Operation: 25 % to 95 % Non-Condensing Transport/Storage: 15 % to 95 % Non-Condensing Pressure: Operation: 700 to 1060 hPa Transport/Storage: 500 to 1060 hPa Warranty Information 1-year warranty.
Shipping Information
Contact Request
Warranty & Returns
1-year warranty.
