Precision performance and sophisticated ergonomics converge in the Philips PagewriterTouch, simply the most advanced EKG on the market today. The large, high resolution Touch display presents the information you need quickly and clearly, including lead quality, ECG snapshots, and the complete print-ready ECG with interpretation. Features and Benefits Designed for high volume hospital use – where the going is rough but quality is critical. A high-resolution 15-inch touch screen clearly displays 10 seconds of all 16 leads, color-coded for signal quality. Preview the full report – waveform and interpretation – before printing to save time and paper. Wireless communication simplifies life, allowing you to quickly download orders and send data to your ECG management system.
Technical Specifications Display Size: 15 inch TFT Signal Quality Indicators Heart Rate: Continuous display of patient heart rate Print Preview: Full screen preview of complete ECG report prior to printing Electrical Mains Power : 100-240 VAC 50/60 Hz Power Consumption: 75 W max Mechanical Dimensions: 45 x 46 x 16 cm (17.7 x 18 x 6.3 in) Weight (includes battery, patient module, lead wires, alligator clips, electrode pack and paper pack): 13 kg (28 lb) Environmental: Operating Conditions: 15 degrees to 35 degrees C (50-95 degrees F); 15% to 70% relative humidity (non-condensing); Up to 4,550 m (15,000 ft.) altitude Storage Conditions: 0 degrees to 40 degrees C (32 degrees to 104 degrees F); 15% to 80% relative humidity (non-condensing); Up to 4,550 m (15,000 ft.) altitude International Standards and Regulations: IEC 60601-1: 1988 +A1:1991 +A2:1995 General Requirement for Safety IEC 60601-2-25: 1993 + A1:1999 Safety of Electrocardiographs UL 2601-1: 1997 US General Requirements for Safety CAN/CSA-C22.2 No. 601.1-M90 S1:1994 B:1996 AAMI EC11 1991: Diagnostic Electrocardiographic Devices CISPR11: 1997 + A1:1999 + A2:2002 Radio Frequency Disturbance, Limits and Methods of Test Group 1 Class B JIST 1202: 1998 Japanese Industrial Standard for Electrocardiographs
