Nonin WristOx2™, Model 3150 Wrist-Worn Pulse Oximeter
Details
Engineered with Nonin Medical’s proven PureSAT® SpO2 technology, the WristOx2™, Model 3150 delivers highly accurate readings in the widest range of patient populations and settings. From the hospital to the home, the WristOx 2™, Model 3150 is ideal for applications including cardio-ambulatory monitoring, remote wireless monitoring and overnight studies. The most advanced wrist-worn pulse oximeter available, the WristOx 2™, Model 3150 features advanced performance and reporting capabilities including enhanced connectivity and increased memory storage. Also available in OEM configuration. Features and Benefits Easy to Use — Simply put your finger in the sensor. Powerful Battery — 48 hours of battery life (non-Bluetooth), 24 hours with continuous Bluetooth using two AAA alkaline batteries. Enhanced Memory — 1,080 hours of non-volatile memory at a four-second sampling rate with additional high resolution variable sampling options of one or two seconds. Convenient Data Transfer — Transfer data securely to nVISION® data management software via Bluetooth wireless or USB connection. New Sensor Line — The new WristOx2 sensors are exclusively designed for use with the new WristOx2™, Model 3150. Software Support — Advanced features such as Six Minute Walk Test (6MWT) or overnight sleep reporting available when used with nVISION data management software. nVISION Combining the WristOx with NONIN’s nVISION® Data Management Software will unleash the full power of your wrist oximeter. nVISION is a Windows®-based software application which provides data analysis and report generation when used with NONIN’s memory products. Purchase nVISION with your WristOx and enjoy advanced features such as: Sensor Activation Mode (sensor connect/disconnect turns WristOx On/Off) Programmed Mode (for pre-programming up to 3 separate Start/Stop times) Set Date, Time and Patient ID Set Patient Data Storage Rate (for choosing trend resolution) Choose a Full or Partial Display (turns off SpO2 and Pulse Rate display for anxious patients) Access 33 Hours of Stored Data (for sleep studies or ambulatory monitoring) Clear Memory
Additional Information
Materials Included Standard Accessories 2 AAA Alkaline Batteries Resuable wristband Purelight 8000SM-WO2 Sensor Operator's Manual Optional Starter Kit Standard accessories Pack of 3 reusable wrist bands USB download cable nVISION software
Tech Specs
Technical Specifications Oxygen Saturation Range (%SpO2): 0% to 100% Pulse Rate Range: 18 to 321 pulses per minute Displays Numeric Displays: 3-digit Indicators Pulse Indicator: Pulse Strength Bar Graph Accuracy Blood Oxygen Saturation: 70 - 100% ± 2 digits (%SpO2 )(±1 SD) Pulse Rate: ±3% Temperature Operating: +23° to +104°F (+-5° to +40°C) Storage/Transportation: -40° to +158°F (-40° to +70°C) Humidity Operating 10% to 90% noncondensing Storage/Transportation 10% to 95% noncondensing Altitude Operating Altitude: Up to 40,000 feet Hyperbaric Pressure: Up to 4 atmospheres Power Requirements: Two 1.5V alkaline AAA batteries Battery Life Operating: Minimum 24 hours of continuous operation Storage: 9 months Dimensions (without sensor or strap): 1.75" wide x 2" high x .75" deep 4.445 cm x 5.08 cm x 1.905 cm Weight (without batteries or wrist strap): ~.88 ounces (24.95 g) Memory Type: Nonvolatile Capacity: 1,080 hours @ 4 sec. data storage rate 540 hours @ 2 sec. data storage rate 270 hours @ 1 sec. data storage rate
Shipping Information
Please Inquire
Warranty & Returns
3-year warranty
