MI 24 touchTymp Tympanometer Screener
Details
Maico offers a reliable all-touch tympanometer with the performance, speed and functionality you have come to trust. Features and Benefits Provides test results within seconds Allows testing from infants to adults Customizable to suit individual needs Full touch-based interface for intuitive handling Innovative probe lights allow for patient-focused operation Probe tone 226 Hz is standard, optional high-frequency probe tone 1,000 Hz available Acoustic reflex frequencies 500 Hz, 1 kHz, 2 kHz, 4 kHz (ipsi- and optional contralateral); optional CIR22 Button Phone for Contralateral available High resolution and quick screen transitions Simply Intuitive The touchTymp combines a full 10.4" touchscreen interface and an innovative icon structure for amazingly intuitive handling. The large color display allows the user to easily change parameters with a maximum of 3 clicks. touchTymp simply improves every professional's daily workflow. Patient Focused Testing Designed to help the user remain focused on the patient rather than on the measurement - the unique light bar on the ergonomic and responsive probe provides a real-time progression of the test. Plus, advanced light indicators show which ear is tested and the test result. Printing Made Easy Test results and reports can be printed quickly using the built-in printer. When placing the probe into the probe holder, the test results will print automatically - touchTymp really is that easy and intuitive.
Additional Information
Materials Included MA24 touchTymp Middle Ear Analyzer Pen Probe Built-in Calibration Cavity Printer Thermal Printer Paper Probe Floss Kit USB Flash Drive USB Cable Impedance Module Software Cleaning Cloth Touchpen Power Supply EarTip Kit 3-5 mm Flanged Eartip, Red (10 pcs) 7 mm Mushroom Eartip, Blue (10 pcs) 9 mm Mushroom Eartip, Green (10 pcs) 11 mm Mushroom Eartip, Blue (10 pcs) 13 mm Mushroom Eartip, Green (10 pcs) 15 mm Mushroom Eartip, Blue (5 pcs) 15 mm Umbrella Eartip, Red (5 pcs) 19 mm Umbrella Eartip, Blue (5 pcs) 19 mm Mushroom Eartip, Yellow (5 pcs) Eartip Removal Tool (1 pc) Probe Tips (3 pcs) Probe Cleaning Tool (1 pc) User Manual
Tech Specs
Technical Specifications Probe Frequency and Intensity: 226 Hz ± 1 %, 85 dBSPL (69 dBHL) ± 1.5 dB Optional high Frequency: 1 kHz ± 1%, 69 dBSPL (69 dBHL) ± 1.5 dB Pressure Range: -600 to +400 daPa Accuracy: ± 5 % or 0.1 ml Volume Range: 0.1 to 8.0 ml at 226 Hz Compliance Range: 0.1 to 8.0 ml at 226 Hz Test Time: 3 - 5 seconds Test Frequencies: 0.5, 1, 2, 4 kHz ± 1% Test method: Ipsilateral; optional contralateral Test Level Ipsilateral: 70 to 105 dBHL Test Level Contralateral: 70 up to 120 dBHL Intensity Setting: Automatic or Fixed Ipsilateral Reflex Test: With or without AGC PC Interface: USB Printer: Fast, virtually silent 4 inch thermal printer Dimensions: 11.81" W x 13.58" D x 5.83" H Weight Device: 7.1 lbs Probe: Lightweight Hand-Held Probe with Light indicators Power Supply: 100 to 240 V~ ± 10 %, 50-60 Hz ± 10%
Shipping Information
Please Inquire
Warranty & Returns
1-Year Warranty
