Perfect for either spot-checks or continuous multi-parameter monitoring, the VitalCare is an easy-to-use monitor with a simple user interface and color-coded LED display. With more than 15 customizable configurations, the VitalCare offers maximum versatility while being extremely cost effective. Features and Benefits Faster, more comfortable readings through the proprietary ComfortCuff® NIBP that measures on inflation Adult, pediatric and neonate settings to test a complete range of patients Adjustable audible and visual alarm settings during continuous monitoring Large, responsive keys on an easy-to-clean membrane keypad to expedite spot-checking A compact design with a built-in handle that is easy to attach to roll stands or wall mounts, making it highly transportable Connectivity to numerous Electronic Medical Records systems Parameters include ComfortCuff® NIBP, Heart Rate and Nellcor OxiMa™ SpO2 technology Included internal printer for on-demand, automatic interval, trends or multi-patient reports
Materials Included VitalCare Vital Signs Monitor 1 DOX SpO2 Adult Reusable Finger Sensor 1 NIBP Hose 1 Small Adult NIBP Cuff 1 Adult NIBP Cuff 1 Large Adult NIBP Cuff 1 Paper Roll 1 Power Cord User Manual
Technical Specifications Non-Invasive Blood Pressure Technique: Oscillometric measure upon inflation Measurement Time: <40 seconds typical; 0 to 300mmHg; standard adult cuff Automatic Measurement Cycles: 1 - 60 minute; 2 - 4 hour; STAT Inflation Pressure Range: 30 to 300mmHg (Adult) 30 to 150mmHg (Pediatric) 20 to 150mmHg (Neonate) Resolution: 1mmHg Clinical Accuracy: SP-10:2002 Transducer Accuracy: ±2mmHg or ±2% of reading, whichever is greater, over full range STAT mode: 5 minutes of consecutive readings Pulse Oximetry Range: 1% to 99% Resolution: 1% Accuracy (DOX only): 70% to 99% range: ±2%; 50% to 69% range: ±3%; <50%: unspecified Method: Dual wavelength LED Audio: Tone with each detected pulse; pitch varies with saturation Heart (Pulse) Rate Range: 20 to 300bpm Accuracy (OxiMax only): Greater of ±1bpm or ±1%, of reading Unspecified for <30 or >240 bpm Update Time: Every second Resolution: 1bpm Pulse Volume: 10 levels or Off Alarms Indication: Audible; Visual Volume: 10 levels or Off Silence: Yes; 2 minutes or permanent Trend Memory Memory: Last 24 hours Parameters: SpO2, pulse rate, NIBP, temperature Report Types: Single Patient or Multi-patient; Selectable formats Displays Type: LED Parameters: NIBP, SpO2; temperature, pulse rate; pulse bar Status: Alarm Silence; Sensor; Low Battery; External Power; Patient Size Text: Alphanumeric LCD Languages: English, French, German, Italian, Portuguese, Spanish, Dutch, Danish System Output Com Port: Serial, RS 232-compatible Printer Type: Thermal array Tabular Mode: 1 - 60 minute intervals; 2 - 24 hour intervals; Auto on BP; Auto on Alarm, Off Mechanical Weight: Base unit with battery: 6.95 lb; 3.15kg Size: Base unit: 8.7" (H) x 7.1" (W) x 6.5” (D); 22cm (H) x 18cm (W) x 16.5cm (D) Power Requirements Voltage: 100 to 240 VAC, 50 to 60 Hz Battery: Sealed lead acid; Life: 8 hours Rechargeable: 6 hours Environmental Operating Temperature: 32º to 113º F; 0º to 45º C Storage Temperature: 23º to 122º F; -5º to 50º C Operating Humidity: 15% to 90%, non-condensing Classification Type of Protection: Class I equipment Degree of Protection: Type CF defibrillator-proof equipment Protection against Ingress: IPX1 rating, Drip-Proof Equipment Office Management Software Compatibility - CSI products are compatible with the following OMS products below. Kodak WINOMS CS by Carestream Dental LLC TiME for OMS by Decision Base, Inc. U.S. HealthRecord powered by TeamLINKS, Inc. Oral Surgery-Exec® by DSN Practice Management Software OMSVision® by HenrySchein Practice Software Windent® by Carestream Dental LLC MD-REPORTS ProVation® Medical gMed Endosoft®
Please Inquire
2-year warranty
