Astotherm Plus 220 - Blood and Infusion Warmer
Details
The most economic model in the Astotherm plus line, the AP220 offers the high quality, low-cost operation medical professionals need for basic blood and infusion warming. The warmer can be ready to use in under one minute, is designed for continuous operation, and is suitable for 97% of clinically relevant transfusion and infusion rates. Features and Benefits Temperature selection: 39°C/41°C/43°C Excessive temperature alarms monitored by three independent sensors Rapid insertion groove for Astotube extension line Optimum heat transfer Microprocessor controlled Audio and visual alarm self-test initiated when warmer is turned on Dry heat warming is easy to clean and inhibits bacteria growth Heat protection sleeve available Materials Included Astotherm Plus 220 Universal Mounting Bracket Heat Protection Sleeve Operator's Manual Power Cord
Tech Specs
Electrical connection: 100-115 VAC ± 10%, 50-60 Hz (230-240 VAC ± 10%, 50-60 Hz) Power consumption: 450 W Power supply cord: Hospital Grade Plug, NEMA, 5-15P, SJO, SJT 18/3 Over-temperature safety cut-off Over-temperature alarm: Visual and acoustic Under-temperature alarm: Visual and acoustic Temperature control: 39° C / 41° C / 43° C Custom temperature control available Heating up time (20°-35° C): Approximately 1 minute Operating mode: Continuous operation Dimensions (Width x Height x Depth): 135 x 145 x 295 mm / 5.31” x 5.71” x 11.61”. Weight: 2.9 kg / 6.39 lbs. Protection class: I Protection level: B, defibrillation-protected Moisture protection: IPX 4 Classification as per European directive 93/42: ll b Notified body: CE 0124 Complies with: IEC 601-1 Health Canada, UL, and FDA listed
Shipping Information
Contact Request
Warranty & Returns
1-year parts and labor warranty.
